Toyota Prius C

2011-12 → 2021-06 · chassis NHP10 · catalogue 125410 · United States

Supported model Data version 2022-07
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Side Moulding

20 part groups · 2 illustrations

Illustrations

Figure 752605B 752605B 2011-12 → — Figure 753524F 753524F 2017-06 → —

Part groups

PNCDescription
60117 Cover Sub-assy, Front Pillar, Upr RH
60118 Cover Sub-assy, Front Pillar, Upr LH
67772G Cap, Front Pillar Cover
75395A Clip, Outside Moulding, NO.1
75551 Moulding, Roof Drip Side Finish, RH
75552 Moulding, Roof Drip Side Finish, LH
75561 Clip, Roof Drip Side Finish Moulding, NO.1
75601A Moulding Sub-assy, Front Fender, RH
75602A Moulding Sub-assy, Front Fender, LH
75605B Moulding Sub-assy, Quarter Outside, RH
75606B Moulding Sub-assy, Quarter Outside, LH
75851 Moulding, Rocker Panel, RH
75852 Moulding, Rocker Panel, LH
75861F Retainer, Rocker Panel Moulding, RH
75862D Retainer, Rocker Panel Moulding, LH
76924G Retainer, Rocker Panel Moulding
76925F Protector, Side Mudguard, RH
76925G Protector, Side Mudguard, RH
76926F Protector, Side Mudguard, LH
76926G Protector, Side Mudguard, LH
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
