Toyota Scion IA/Yaris R/IA
2015-06 → present · chassis DADW,DAE#,DB7P,DD1#,DDF#,DM0# · catalogue 141480 · United States
Supported model
Data version 2019-09
Back Door Panel & Glass
6 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 64780A | Panel Assy, Back Door Trim |
| 64790B | Panel Assy, Back Door Trim, Upper |
| 67005 | Panel Sub-assy, Back Door |
| 67881A | Weatherstrip, Back Door |
| 68131 | Glass, Back Door |
| 74811D | Handle, Door Pull |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
