Toyota Yaris/Vios/Limo
2013-04 → present · chassis NCP15#,NSP15# · catalogue 149330 · United States
Supported model
Data version 2019-11
Mudguard & Spoiler
24 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 52161G | Piece, Rear Bumper |
| 65631D | Plate, Rear Wheel House, Front RH |
| 65632D | Plate, Rear Wheel House, Front LH |
| 75392D | Retainer, Outside Moulding |
| 75867B | Clip, Rocker Panel Moulding |
| 75895F | Tape, Moulding, NO.1 |
| 75895G | Tape, Moulding, NO.1 |
| 76851A | Cover, Front Spoiler, RH |
| 76852A | Cover, Front Spoiler, LH |
| 76865E | Protector, Rocker Panel Moulding, NO.5 |
| 76866E | Protector, Rocker Panel Moulding, NO.6 |
| 76871 | Spoiler, Rear |
| 76873A | Protector, Rear Spoiler, RH |
| 76874B | Protector, Rear Spoiler, LH |
| 76877D | Protector, Front Spoiler Side, RH |
| 76878A | Protector, Front Spoiler Side, LH |
| 76879 | Clip, Rear Spoiler, NO.1 |
| 76893A | Cover, Rear Spoiler, RH |
| 76894 | Cover, Rear Spoiler, LH |
| 76915F | Mudguard, Side, FR RH |
| 76916F | Mudguard, Side, FR LH |
| 76924 | Retainer, Side Mudguard, NO.2 |
| 76925D | Protector, Side Mudguard, RH |
| 76926D | Protector, Side Mudguard, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
