Toyota Corolla Sed (JPP)
2002-04 → 2007-06 · chassis ZZE130 · catalogue 151450 · United States
Discontinued model
Data version 2008-06
Instrument Panel & Glove Compartment
32 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 50540 | DO0R Assy, Airbag Passenger |
| 55054 | Stopper Sub-assy, Glove Compartment Door |
| 55302A | Panel Sub-assy, Instrument, Upper |
| 55303B | Panel Sub-assy, Instrument, Lower |
| 55306A | Brace Sub-assy, Instrument Panel, NO.1 |
| 55308C | Bracket Sub-assy, Instrument Panel, Center |
| 55312A | Clip, Instrument Panel |
| 55331 | Reinforcement, Instrument Panel |
| 55343B | Brace, Instrument Panel TO Cowl, Center |
| 55355 | Cushion, Instrument Panel, NO.1 |
| 55368C | Bracket, Meter Mounting |
| 55394B | Bolt, Instrument Panel |
| 55403 | Hood Sub-assy, Meter |
| 55405B | Panel Sub-assy, Instrument Cluster Finish, Center |
| 55411G | Panel, Instrument Cluster Finish, NO.1 |
| 55440D | Box Assy, Instrument Panel |
| 55441C | Box, Instrument Panel Coin |
| 55441E | Box, Instrument Panel |
| 55444A | Spring, Instrument Panel Box |
| 55444C | Spring, Instrument Panel Box |
| 55464C | Insert, Instrument Panel Lower Pad, RH |
| 55465C | Insert, Instrument Panel Lower Pad, LH |
| 55503B | Cushion(FOR GLOVE COMPARTMENT) |
| 55521C | Cover, Stereo Opening |
| 55539 | Cover, Spare Switch Hole |
| 55548A | Cover, Instrument Panel Hole |
| 55550 | Door Assy, Glove Compartment |
| 55560A | Lock Assy, Glove Compartment Door |
| 55650 | Register Assy, Instrument Panel, NO.1 |
| 55670 | Register Assy, Instrument Panel, NO.3 |
| 73970A | Airbag Assy, Instrument Panel Passenger |
| 81942C | Sheet, Heater Control Name |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
