Toyota Corolla Jpp
2007-12 → 2013-08 · chassis ZRE142 · catalogue 151460 · United States
Supported model
Data version 2014-02
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 11401G — Sensor, Crank Position | ||||
| 90919-05070 note |
Sensor, Crank Position
2007-12 → 2010-12
ended
|
2ZRFE ZRE142 JPP | — | |
| 90919-A5004 note |
Sensor, Crank Position
2008-07 → 2010-12
ended
|
2ZRFE ZRE142 JPP | — | |
| 90919-05070 note |
Sensor, Crank Position
2010-12 → 2013-08
ended
|
2ZRFE ZRE142 JPP | — | |
| 90919-A5004 note |
Sensor, Crank Position
2010-12 → 2013-08
ended
|
2ZRFE ZRE142 JPP | — | |
| 11415 — Cock Sub-assy, Water Drain(FOR CYLINDER BLOCK) | ||||
| 90910-09129 note |
Cock Sub-assy, Water Drain(FOR CYLINDER BLOCK)
2007-12 → 2010-02
ended
|
2ZRFE ZRE142 JPP | — | |
| 90910-09129 note |
Cock Sub-assy, Water Drain(FOR CYLINDER BLOCK)
2008-07 → 2010-03
ended
|
2ZRFE ZRE142 JPP | — | |
| 11415A — Plug, Water Drain Cock(FOR CYLINDER BLOCK) | ||||
| 90910-09087 note |
Plug, Water Drain Cock(FOR CYLINDER BLOCK)
2007-12 → 2010-02
ended
|
2ZRFE ZRE142 JPP | — | |
| 90910-09087 note |
Plug, Water Drain Cock(FOR CYLINDER BLOCK)
2008-07 → 2010-03
ended
|
2ZRFE ZRE142 JPP | — | |
| 11432A — Plug, W/Head Taper Screw, NO.1 | ||||
| 90345-52001 note |
Plug, W/Head Taper Screw, NO.1
2010-02 → 2010-12
ended
|
2ZRFE ZRE142 JPP | — | |
| 90345-52001 note |
Plug, W/Head Taper Screw, NO.1
2010-03 → 2010-12
ended
|
2ZRFE ZRE142 JPP | — | |
| 90345-53006 note |
Plug, W/Head Taper Screw, NO.1
2007-12 → 2010-12
ended
|
2ZRFE ZRE142 JPP | — | |
| 90345-52001 note |
Plug, W/Head Taper Screw, NO.1
2010-12 → 2013-08
ended
|
2ZRFE ZRE142 JPP | — | |
| 90345-53006 note |
Plug, W/Head Taper Screw, NO.1
2010-12 → 2013-08
ended
|
2ZRFE ZRE142 JPP | — | |
| 11434B — Pin, Straight(FOR CLUTCH HOUSING SET) | ||||
| 90250-10113 note |
Pin, Straight(FOR CLUTCH HOUSING SET)
2007-12 → 2010-12
ended
|
2ZRFE ZRE142 JPP | — | |
| 90250-10113 note |
Pin, Straight(FOR CLUTCH HOUSING SET)
2010-12 → 2013-08
ended
|
2ZRFE ZRE142 JPP | — | |
| 11434Y — Pin, Straight(FOR OIL PAN) | ||||
| 90250-08074 note |
Pin, Straight(FOR OIL PAN)
2007-12 → 2009-03
ended
|
2ZRFE ZRE142 JPP | — | |
| 90250-08120 note |
Pin, Straight(FOR OIL PAN)
2009-03 → 2010-12
ended
|
2ZRFE ZRE142 JPP | — | |
| 90250-08120 note |
Pin, Straight(FOR OIL PAN)
2010-12 → 2013-08
ended
|
2ZRFE ZRE142 JPP | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
