Toyota Corolla Jpp
2007-12 → 2013-08 · chassis ZRE142 · catalogue 151460 · United States
Supported model
Data version 2014-02
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 19100P — Plug, Spark | ||||
| 90919-01253 note |
Plug, Spark
2007-12 → 2010-12
ended
|
2ZRFE ZRE142 JPP | — | |
| 90919-01253 note |
Plug, Spark
2010-12 → 2013-08
ended
|
2ZRFE ZRE142 JPP | — | |
| 19500 — Coil Assy, Ignition | ||||
| 90919-02252 |
Coil Assy, Ignition
2007-12 → 2010-04
ended
|
2ZRFE ZRE142 JPP | — | |
| 90919-02258 |
Coil Assy, Ignition
2010-04 → 2010-12
ended
|
2ZRFE ZRE142 JPP | — | |
| 90919-02258 |
Coil Assy, Ignition
2010-12 → 2013-08
ended
|
2ZRFE ZRE142 JPP | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
