Toyota Corolla Jpp
2007-12 → 2013-08 · chassis ZRE142 · catalogue 151460 · United States
Supported model
Data version 2014-02
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 44610 — Booster Assy, Brake | ||||
| 44610-12A80 note |
Booster Assy, Brake
2007-12 → 2008-02
ended
|
ZRE142 JPP | — | |
| 44610-12A81 note |
Booster Assy, Brake
2008-03 → 2009-01
ended
|
ZRE142 JPP | — | |
| 44610-12A81 |
Booster Assy, Brake
2009-01 → 2010-11
ended
|
ZRE142 JPP | — | |
| 44610-12D20 |
Booster Assy, Brake
2007-12 → 2008-03
ended
|
ZRE142 JPP | — | |
| 44610-12D21 |
Booster Assy, Brake
2008-03 → 2009-01
ended
|
ZRE142 JPP | — | |
| 44610-12G00 |
Booster Assy, Brake
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 44696 — Grommet, Check Valve | ||||
| 90480-24439 |
Grommet, Check Valve
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 90480-24439 |
Grommet, Check Valve
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 44730 — Valve Assy, Vacuum Check(FOR BRAKE) | ||||
| 44730-12070 |
Valve Assy, Vacuum Check(FOR BRAKE)
2007-12 → 2008-07
ended
|
ZRE142 JPP | — | |
| 44730-14050 note |
Valve Assy, Vacuum Check(FOR BRAKE)
2007-12 → 2009-01
ended
|
ZRE142 JPP | — | |
| 44730-14050 |
Valve Assy, Vacuum Check(FOR BRAKE)
2009-01 → 2010-12
ended
|
ZRE142 JPP | — | |
| 44730-20170 |
Valve Assy, Vacuum Check(FOR BRAKE)
2008-08 → 2009-01
ended
|
ZRE142 JPP | — | |
| 44730-14050 |
Valve Assy, Vacuum Check(FOR BRAKE)
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 44763C — Tube, Hose TO Hose, NO.2 | ||||
| 44763-12500 |
Tube, Hose TO Hose, NO.2
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 44763-12500 |
Tube, Hose TO Hose, NO.2
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 44773F — Hose, Union TO Check Valve | ||||
| 44773-12860 |
Hose, Union TO Check Valve
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 44773-12860 |
Hose, Union TO Check Valve
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 44773G — Clip(FOR UNION TO CHECK VALVE HOSE) | ||||
| 96133-41500 |
Clip(FOR UNION TO CHECK VALVE HOSE)
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 96133-41500 |
Clip(FOR UNION TO CHECK VALVE HOSE)
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 44774 — Hose, Union TO Connector Tube | ||||
| 44774-12700 |
Hose, Union TO Connector Tube
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 44774-12700 |
Hose, Union TO Connector Tube
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 44774A — Clip(FOR UNION TO CONNECTOR TUBE HOSE) | ||||
| 96133-41500 |
Clip(FOR UNION TO CONNECTOR TUBE HOSE)
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 96133-41500 |
Clip(FOR UNION TO CONNECTOR TUBE HOSE)
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 44785 — Gasket, Brake Booster | ||||
| 44785-12040 |
Gasket, Brake Booster
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 44785-12040 |
Gasket, Brake Booster
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 47264D — Clevis, Brake Master Cylinder Push Rod | ||||
| 47264-63020 |
Clevis, Brake Master Cylinder Push Rod
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 47264-68010 |
Clevis, Brake Master Cylinder Push Rod
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
