Toyota Corolla Jpp

2007-12 → 2013-08 · chassis ZRE142 · catalogue 151460 · United States

Supported model Data version 2014-02
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes
Exploded illustration 675342E 69803 — REGULATOR SUB-ASSY, REAR DOOR WINDOW, RH (4 parts) 69804 — REGULATOR SUB-ASSY, REAR DOOR WINDOW, LH (4 parts) 69905B — CHANNEL SUB-ASSY, REAR DOOR GLASS, RH (2 parts) 69906B — CHANNEL SUB-ASSY, REAR DOOR GLASS, LH (2 parts) 69975A — FILLER, REAR DOOR GLASS CHANNEL (2 parts) 85710F — MOTOR ASSY, POWER WINDOW REGULATOR, RH (4 parts) 85720E — MOTOR ASSY, POWER WINDOW REGULATOR, LH (4 parts) 9016850040 — not listed in this catalogue 9010506260 — not listed in this catalogue 9010506260 — not listed in this catalogue 68750 — HINGE ASSY, REAR DOOR, UPPER RH (3 parts) 68760 — HINGE ASSY, REAR DOOR, UPPER LH (3 parts) 68770 — HINGE ASSY, REAR DOOR, LOWER RH (2 parts) 68780 — HINGE ASSY, REAR DOOR, LOWER LH (2 parts) 69260E — HANDLE ASSY, REAR DOOR WINDOW REGULATOR (10 parts) 69272B — PLATE, REAR DOOR REGULATOR INSIDE HANDLE (5 parts) 69830A — REGULATOR ASSY, REAR DOOR WINDOW, RH (2 parts) 69840A — REGULATOR ASSY, REAR DOOR WINDOW, LH (2 parts) 9010508291 — not listed in this catalogue 9010508291 — not listed in this catalogue 9010508448 — not listed in this catalogue 9010508448 — not listed in this catalogue 69260F — RING, SHAFT SNAP(FOR REAR DOOR WINDOW REGULATOR HANDLE) (5 parts) 6705 — not listed in this catalogue
675342E · 16 callouts, 8 unlisted Full size ↗
Dashed callouts are standard fasteners the factory draws but does not list as separate parts — there is no part number behind them.
56 parts on this figure
Part number Description Fitment Price
68750 — Hinge Assy, Rear Door, Upper RH
68750-20121 Hinge Assy, Rear Door, Upper RH
2007-12 → 2010-12 ended
ZRE142 JPP —
68750-20121 Hinge Assy, Rear Door, Upper RH
2010-12 → 2012-05 ended
ZRE142 JPP —
68750-20122 Hinge Assy, Rear Door, Upper RH
2012-06 → 2013-08 ended
ZRE142 JPP —
68760 — Hinge Assy, Rear Door, Upper LH
68760-20121 Hinge Assy, Rear Door, Upper LH
2007-12 → 2010-12 ended
ZRE142 JPP —
68760-20121 Hinge Assy, Rear Door, Upper LH
2010-12 → 2012-05 ended
ZRE142 JPP —
68760-20122 Hinge Assy, Rear Door, Upper LH
2012-06 → 2013-08 ended
ZRE142 JPP —
68770 — Hinge Assy, Rear Door, Lower RH
68770-52031 Hinge Assy, Rear Door, Lower RH
2007-12 → 2010-12 ended
ZRE142 JPP —
68770-52031 Hinge Assy, Rear Door, Lower RH
2010-12 → 2013-08 ended
ZRE142 JPP —
68780 — Hinge Assy, Rear Door, Lower LH
68780-52031 Hinge Assy, Rear Door, Lower LH
2007-12 → 2010-12 ended
ZRE142 JPP —
68780-52031 Hinge Assy, Rear Door, Lower LH
2010-12 → 2013-08 ended
ZRE142 JPP —
69260E — Handle Assy, Rear Door Window Regulator
69260-52070-B1 note Handle Assy, Rear Door Window Regulator
2007-12 → 2010-12 ended
ZRE142 JPP STD —
69260-52070-B1 note Handle Assy, Rear Door Window Regulator
2007-12 → 2010-12 ended
ZRE142 JPP STD —
69260-52070-E0 note Handle Assy, Rear Door Window Regulator
2007-12 → 2010-12 ended
ZRE142 JPP STD —
69260-52070-E0 note Handle Assy, Rear Door Window Regulator
2007-12 → 2010-12 ended
ZRE142 JPP STD —
69260-52070-B1 note Handle Assy, Rear Door Window Regulator
2010-12 → 2013-08 ended
ZRE142 JPP STD —
69260-52070-B1 note Handle Assy, Rear Door Window Regulator
2010-12 → 2013-08 ended
ZRE142 JPP STD —
69260-52070-B1 note Handle Assy, Rear Door Window Regulator
2010-12 → 2013-08 ended
ZRE142 JPP STD —
69260-52070-E0 note Handle Assy, Rear Door Window Regulator
2010-12 → 2013-08 ended
ZRE142 JPP STD —
69260-52070-E0 note Handle Assy, Rear Door Window Regulator
2010-12 → 2013-08 ended
ZRE142 JPP STD —
69260-52070-E0 note Handle Assy, Rear Door Window Regulator
2010-12 → 2013-08 ended
ZRE142 JPP STD —
69260F — Ring, Shaft Snap(FOR REAR DOOR WINDOW REGULATOR HANDLE)
90520-01274 Ring, Shaft Snap(FOR REAR DOOR WINDOW REGULATOR HANDLE)
2007-12 → 2010-12 ended
ZRE142 JPP STD —
90520-01274 note Ring, Shaft Snap(FOR REAR DOOR WINDOW REGULATOR HANDLE)
2007-12 → 2010-12 ended
ZRE142 JPP STD —
90520-01274 Ring, Shaft Snap(FOR REAR DOOR WINDOW REGULATOR HANDLE)
2010-12 → 2013-08 ended
ZRE142 JPP STD —
90520-01274 note Ring, Shaft Snap(FOR REAR DOOR WINDOW REGULATOR HANDLE)
2010-12 → 2013-08 ended
ZRE142 JPP STD —
90520-01274 note Ring, Shaft Snap(FOR REAR DOOR WINDOW REGULATOR HANDLE)
2010-12 → 2013-08 ended
ZRE142 JPP STD —
69272B — Plate, Rear Door Regulator Inside Handle
69268-12020 Plate, Rear Door Regulator Inside Handle
2007-12 → 2010-12 ended
ZRE142 JPP STD —
69268-12020 note Plate, Rear Door Regulator Inside Handle
2007-12 → 2010-12 ended
ZRE142 JPP STD —
69268-12020 note Plate, Rear Door Regulator Inside Handle
2010-12 → 2013-08 ended
ZRE142 JPP STD —
69268-12020 note Plate, Rear Door Regulator Inside Handle
2010-12 → 2013-08 ended
ZRE142 JPP STD —
69268-12020 Plate, Rear Door Regulator Inside Handle
2010-12 → 2013-08 ended
ZRE142 JPP STD —
69803 — Regulator Sub-assy, Rear Door Window, RH
69803-12180 Regulator Sub-assy, Rear Door Window, RH
2007-12 → 2010-12 ended
ZRE142 JPP LE —
69803-12180 note Regulator Sub-assy, Rear Door Window, RH
2007-12 → 2010-12 ended
ZRE142 JPP STD —
69803-12180 Regulator Sub-assy, Rear Door Window, RH
2010-12 → 2013-08 ended
ZRE142 JPP LE —
69803-12180 note Regulator Sub-assy, Rear Door Window, RH
2010-12 → 2013-08 ended
ZRE142 JPP STD —
69804 — Regulator Sub-assy, Rear Door Window, LH
69804-12180 Regulator Sub-assy, Rear Door Window, LH
2007-12 → 2010-12 ended
ZRE142 JPP LE —
69804-12180 note Regulator Sub-assy, Rear Door Window, LH
2007-12 → 2010-12 ended
ZRE142 JPP STD —
69804-12180 Regulator Sub-assy, Rear Door Window, LH
2010-12 → 2013-08 ended
ZRE142 JPP LE —
69804-12180 note Regulator Sub-assy, Rear Door Window, LH
2010-12 → 2013-08 ended
ZRE142 JPP STD —
69830A — Regulator Assy, Rear Door Window, RH
69830-12450 Regulator Assy, Rear Door Window, RH
2007-12 → 2010-12 ended
ZRE142 JPP STD —
69830-12450 Regulator Assy, Rear Door Window, RH
2010-12 → 2013-08 ended
ZRE142 JPP STD —
69840A — Regulator Assy, Rear Door Window, LH
69840-12440 Regulator Assy, Rear Door Window, LH
2007-12 → 2010-12 ended
ZRE142 JPP STD —
69840-12440 Regulator Assy, Rear Door Window, LH
2010-12 → 2013-08 ended
ZRE142 JPP STD —
69905B — Channel Sub-assy, Rear Door Glass, RH
69905-12200 Channel Sub-assy, Rear Door Glass, RH
2007-12 → 2010-12 ended
ZRE142 JPP —
69905-12200 Channel Sub-assy, Rear Door Glass, RH
2010-12 → 2013-08 ended
ZRE142 JPP —
69906B — Channel Sub-assy, Rear Door Glass, LH
69906-12190 Channel Sub-assy, Rear Door Glass, LH
2007-12 → 2010-12 ended
ZRE142 JPP —
69906-12190 Channel Sub-assy, Rear Door Glass, LH
2010-12 → 2013-08 ended
ZRE142 JPP —
69975A — Filler, Rear Door Glass Channel
69975-12020 Filler, Rear Door Glass Channel
2007-12 → 2010-12 ended
ZRE142 JPP —
69975-12020 Filler, Rear Door Glass Channel
2010-12 → 2013-08 ended
ZRE142 JPP —
85710F — Motor Assy, Power Window Regulator, RH
85720-35140 Motor Assy, Power Window Regulator, RH
2007-12 → 2010-12 ended
ZRE142 JPP LE —
85720-35140 note Motor Assy, Power Window Regulator, RH
2007-12 → 2010-12 ended
ZRE142 JPP STD —
85720-35140 Motor Assy, Power Window Regulator, RH
2010-12 → 2013-08 ended
ZRE142 JPP LE —
85720-35140 note Motor Assy, Power Window Regulator, RH
2010-12 → 2013-08 ended
ZRE142 JPP STD —
85720E — Motor Assy, Power Window Regulator, LH
85710-35180 Motor Assy, Power Window Regulator, LH
2007-12 → 2010-12 ended
ZRE142 JPP LE —
85710-35180 note Motor Assy, Power Window Regulator, LH
2007-12 → 2010-12 ended
ZRE142 JPP STD —
85710-35180 Motor Assy, Power Window Regulator, LH
2010-12 → 2013-08 ended
ZRE142 JPP LE —
85710-35180 note Motor Assy, Power Window Regulator, LH
2010-12 → 2013-08 ended
ZRE142 JPP STD —
No quantity column: the factory catalogue records which parts a vehicle takes, never how many.
