Toyota Corolla Jpp
2007-12 → 2013-08 · chassis ZRE142 · catalogue 151460 · United States
Supported model
Data version 2014-02
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 77251B — Tube, Fuel Main | ||||
| 77251-12790 |
Tube, Fuel Main
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 77251-12790 |
Tube, Fuel Main
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 77261D — Tube, Fuel Tank TO Canister | ||||
| 77261-12550 |
Tube, Fuel Tank TO Canister
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 77261-12550 |
Tube, Fuel Tank TO Canister
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 77285A — Support, Fuel Return And Main Tube | ||||
| 77285-42110 |
Support, Fuel Return And Main Tube
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 77285-42110 |
Support, Fuel Return And Main Tube
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 77285D — Clamp, Fuel Tube, NO.1 | ||||
| 77285-50040 |
Clamp, Fuel Tube, NO.1
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 77285-50040 |
Clamp, Fuel Tube, NO.1
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 77286M — Clamp, Fuel Tube, NO.6 | ||||
| 77285-12130 |
Clamp, Fuel Tube, NO.6
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 77285-12130 |
Clamp, Fuel Tube, NO.6
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 77298A — Clamp, Fuel Tube, NO.4 | ||||
| 77298-52070 |
Clamp, Fuel Tube, NO.4
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 77298-52070 |
Clamp, Fuel Tube, NO.4
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 77299A — Clamp, Fuel Tube, NO.5 | ||||
| 77299-12030 |
Clamp, Fuel Tube, NO.5
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 77299-12030 |
Clamp, Fuel Tube, NO.5
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
