Toyota Corolla Jpp
2007-12 → 2013-08 · chassis ZRE142 · catalogue 151460 · United States
Supported model
Data version 2014-02
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 28800 — Battery | ||||
| 28800-43262 note |
Battery
2007-12 → 2010-12
ended
|
2ZRFE ZRE142 JPP | — | |
| 28800-42041 note |
Battery
2010-12 → 2013-08
ended
|
2ZRFE ZRE142 JPP LE | — | |
| 28800-42061 note |
Battery
2010-12 → 2012-04
ended
|
2ZRFE ZRE142 JPP LE | — | |
| 28800-42062 note |
Battery
2012-05 → 2013-08
ended
|
2ZRFE ZRE142 JPP LE | — | |
| 28800-43262 note |
Battery
2010-12 → 2013-08
ended
|
2ZRFE ZRE142 JPP | — | |
| 28800A — Terminal, Battery Positive | ||||
| 90982-05054 |
Terminal, Battery Positive
2007-12 → 2010-12
ended
|
2ZRFE ZRE142 JPP | — | |
| 90982-05054 |
Terminal, Battery Positive
2010-12 → 2013-08
ended
|
2ZRFE ZRE142 JPP | — | |
| 28800D — Cover, Connector(FOR BATTERY TERMINAL) | ||||
| 82821-12490 |
Cover, Connector(FOR BATTERY TERMINAL)
2007-12 → 2010-12
ended
|
2ZRFE ZRE142 JPP | — | |
| 82821-12490 |
Cover, Connector(FOR BATTERY TERMINAL)
2010-12 → 2013-08
ended
|
2ZRFE ZRE142 JPP | — | |
| 28800J — Terminal, Battery Negative | ||||
| 90982-06070 |
Terminal, Battery Negative
2007-12 → 2010-12
ended
|
2ZRFE ZRE142 JPP | — | |
| 90982-06070 |
Terminal, Battery Negative
2010-12 → 2013-08
ended
|
2ZRFE ZRE142 JPP | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
