Toyota Corolla Jpp
2007-12 → 2013-08 · chassis ZRE142 · catalogue 151460 · United States
Supported model
Data version 2014-02
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 72277A — Protector, Seat Slide Position Sensor | ||||
| 72277-33010 |
Protector, Seat Slide Position Sensor
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 72277-33010 |
Protector, Seat Slide Position Sensor
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 89170 — Sensor Assy, Airbag | ||||
| 89170-02760 |
Sensor Assy, Airbag
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 89170-02A60 |
Sensor Assy, Airbag
2010-12 → 2012-03
ended
|
ZRE142 JPP | — | |
| 89170-02A60 note |
Sensor Assy, Airbag
2012-03 → 2013-08
ended
|
ZRE142 JPP LE | — | |
| 89170-02D51 |
Sensor Assy, Airbag
2012-03 → 2012-04
ended
|
ZRE142 JPP | — | |
| 89170-02D52 |
Sensor Assy, Airbag
2012-07 → 2012-08
ended
|
ZRE142 JPP | — | |
| 89170-02D53 |
Sensor Assy, Airbag
2012-08 → 2013-08
ended
|
ZRE142 JPP | — | |
| 89173A — Sensor, Airbag, Front RH | ||||
| 89173-09470 |
Sensor, Airbag, Front RH
2007-12 → 2008-07
ended
|
ZRE142 JPP | — | |
| 89173-09510 |
Sensor, Airbag, Front RH
2008-07 → 2010-12
ended
|
ZRE142 JPP | — | |
| 89173-09690 |
Sensor, Airbag, Front RH
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 89174A — Sensor, Airbag, Front LH | ||||
| 89173-09470 |
Sensor, Airbag, Front LH
2007-12 → 2008-07
ended
|
ZRE142 JPP | — | |
| 89173-09510 |
Sensor, Airbag, Front LH
2008-07 → 2010-12
ended
|
ZRE142 JPP | — | |
| 89173-09690 |
Sensor, Airbag, Front LH
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 89178A — Sensor, Seat Position Airbag | ||||
| 89178-33040 |
Sensor, Seat Position Airbag
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 89178-33040 |
Sensor, Seat Position Airbag
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 89833 — Sensor, Airbag, Rear RH | ||||
| 89831-02090 |
Sensor, Airbag, Rear RH
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 89831-02120 |
Sensor, Airbag, Rear RH
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 89834 — Sensor, Airbag, Rear LH | ||||
| 89831-02090 |
Sensor, Airbag, Rear LH
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 89831-02120 |
Sensor, Airbag, Rear LH
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 89835 — Sensor, Door Side Airbag, LH | ||||
| 89831-0C090 |
Sensor, Door Side Airbag, LH
2012-03 → 2013-08
ended
|
ZRE142 JPP | — | |
| 89831-0C090 note |
Sensor, Door Side Airbag, LH
2012-03 → 2013-08
ended
|
ZRE142 JPP LE | — | |
| 89860 — Sensor Assy, Side Airbag, RH | ||||
| 89831-01010 |
Sensor Assy, Side Airbag, RH
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 89831-02110 |
Sensor Assy, Side Airbag, RH
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 89860A — Sensor Assy, Side Airbag, LH | ||||
| 89831-01010 |
Sensor Assy, Side Airbag, LH
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 89831-02110 |
Sensor Assy, Side Airbag, LH
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 89865 — Sensor, Door Side Airbag, RH | ||||
| 89831-0C090 |
Sensor, Door Side Airbag, RH
2012-03 → 2013-08
ended
|
ZRE142 JPP | — | |
| 89831-0C090 note |
Sensor, Door Side Airbag, RH
2012-03 → 2013-08
ended
|
ZRE142 JPP LE | — | |
| 89952 — Computer, Occupant Detection | ||||
| 89952-01010 |
Computer, Occupant Detection
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 89952-01010 |
Computer, Occupant Detection
2010-12 → 2011-08
ended
|
ZRE142 JPP | — | |
| 89952-01011 |
Computer, Occupant Detection
2011-09 → 2013-08
ended
|
ZRE142 JPP | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
