Toyota Corolla Jpp
2007-12 → 2013-08 · chassis ZRE142 · catalogue 151460 · United States
Supported model
Data version 2014-02
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 84746A — Switch, Tire Pressure Warning, NO.1 | ||||
| 84746-50010 |
Switch, Tire Pressure Warning, NO.1
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 84746-50010 |
Switch, Tire Pressure Warning, NO.1
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 84746-50010 note |
Switch, Tire Pressure Warning, NO.1
2010-12 → 2013-08
ended
|
ZRE142 JPP LE | — | |
| 89760C — Receiver Assy, Tire Pressure Monitor | ||||
| 89760-12010 |
Receiver Assy, Tire Pressure Monitor
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 89760-12010 |
Receiver Assy, Tire Pressure Monitor
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 89760-12010 note |
Receiver Assy, Tire Pressure Monitor
2010-12 → 2013-08
ended
|
ZRE142 JPP LE | — | |
| 89769 — Computer, Tire Pressure Monitor | ||||
| 89769-12010 |
Computer, Tire Pressure Monitor
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 89769-12010 |
Computer, Tire Pressure Monitor
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 89769-12010 note |
Computer, Tire Pressure Monitor
2010-12 → 2013-08
ended
|
ZRE142 JPP LE | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
