Toyota Corolla Jpp
2007-12 → 2013-08 · chassis ZRE142 · catalogue 151460 · United States
Supported model
Data version 2014-02
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 86160 — Speaker Assy, Front NO.1 | ||||
| 86160-2B580 |
Speaker Assy, Front NO.1
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 86160-2B580 |
Speaker Assy, Front NO.1
2010-12 → 2011-06
ended
|
ZRE142 JPP | — | |
| 86160-52330 |
Speaker Assy, Front NO.1
2011-07 → 2013-08
ended
|
ZRE142 JPP | — | |
| 86160B — Speaker Assy, Rear | ||||
| 86160-1A180 |
Speaker Assy, Rear
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 86160-1A180 |
Speaker Assy, Rear
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 86160P — Speaker Assy, Front NO.2 | ||||
| 86160-68010 note |
Speaker Assy, Front NO.2
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 86160-68010 note |
Speaker Assy, Front NO.2
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 86160-52340 |
Speaker Assy, Front NO.2
2011-09 → 2013-08
ended
|
ZRE142 JPP LE | — | |
| 86160-52340 note |
Speaker Assy, Front NO.2
2011-12 → 2013-08
ended
|
ZRE142 JPP STD | — | |
| 86160-68010 |
Speaker Assy, Front NO.2
2010-12 → 2011-09
ended
|
ZRE142 JPP LE | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
