Toyota Corolla Jpp
2007-12 → 2013-08 · chassis ZRE142 · catalogue 151460 · United States
Supported model
Data version 2014-02
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 82210K — Harness Assy, Air Conditioner | ||||
| 82212-12010 note |
Harness Assy, Air Conditioner
2007-12 → 2010-12
ended
|
ZRE142 JPP LE | — | |
| 82212-12010 note |
Harness Assy, Air Conditioner
2007-12 → 2010-12
ended
|
ZRE142 JPP LE | — | |
| 82212-12010 note |
Harness Assy, Air Conditioner
2010-12 → 2013-08
ended
|
ZRE142 JPP LE | — | |
| 82212-12010 note |
Harness Assy, Air Conditioner
2010-12 → 2011-02
ended
|
ZRE142 JPP LE | — | |
| 87050 — Radiator Assy, Air Conditioner | ||||
| 87050-12290 note |
Radiator Assy, Air Conditioner
2007-12 → 2010-04
ended
|
ZRE142 JPP LE | — | |
| 87050-12291 note |
Radiator Assy, Air Conditioner
2010-05 → 2010-12
ended
|
ZRE142 JPP LE | — | |
| 87050-12300 note |
Radiator Assy, Air Conditioner
2007-12 → 2010-04
ended
|
ZRE142 JPP LE | — | |
| 87050-12301 note |
Radiator Assy, Air Conditioner
2010-05 → 2010-12
ended
|
ZRE142 JPP LE | — | |
| 87050-12390 |
Radiator Assy, Air Conditioner
2007-12 → 2010-04
ended
|
ZRE142 JPP | — | |
| 87050-12391 |
Radiator Assy, Air Conditioner
2010-05 → 2010-12
ended
|
ZRE142 JPP | — | |
| 87050-12400 note |
Radiator Assy, Air Conditioner
2007-12 → 2010-04
ended
|
ZRE142 JPP | — | |
| 87050-12401 note |
Radiator Assy, Air Conditioner
2010-05 → 2010-12
ended
|
ZRE142 JPP | — | |
| 87050-12301 note |
Radiator Assy, Air Conditioner
2010-12 → 2011-02
ended
|
ZRE142 JPP LE | — | |
| 87050-12301 note |
Radiator Assy, Air Conditioner
2011-02 → 2013-08
ended
|
ZRE142 JPP LE | — | |
| 87050-12391 |
Radiator Assy, Air Conditioner
2010-12 → 2011-02
ended
|
ZRE142 JPP | — | |
| 87050-12391 note |
Radiator Assy, Air Conditioner
2011-02 → 2013-08
ended
|
ZRE142 JPP | — | |
| 87050-12401 note |
Radiator Assy, Air Conditioner
2010-12 → 2011-02
ended
|
ZRE142 JPP | — | |
| 87050-12401 |
Radiator Assy, Air Conditioner
2011-02 → 2013-08
ended
|
ZRE142 JPP | — | |
| 87103B — Motor Sub-assy, Blower W/Fan | ||||
| 87103-12080 note |
Motor Sub-assy, Blower W/Fan
2007-12 → 2010-12
ended
|
ZRE142 JPP LE | — | |
| 87103-12080 note |
Motor Sub-assy, Blower W/Fan
2007-12 → 2010-12
ended
|
ZRE142 JPP LE | — | |
| 87103-42090 |
Motor Sub-assy, Blower W/Fan
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 87103-12080 note |
Motor Sub-assy, Blower W/Fan
2010-12 → 2011-02
ended
|
ZRE142 JPP LE | — | |
| 87103-12080 note |
Motor Sub-assy, Blower W/Fan
2011-02 → 2013-08
ended
|
ZRE142 JPP LE | — | |
| 87103-42090 |
Motor Sub-assy, Blower W/Fan
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 87106H — Servo Sub-assy, Damper(FOR AIRMIX) | ||||
| 87106-12170 note |
Servo Sub-assy, Damper(FOR AIRMIX)
2007-12 → 2010-12
ended
|
ZRE142 JPP LE | — | |
| 87106-12170 note |
Servo Sub-assy, Damper(FOR AIRMIX)
2007-12 → 2010-12
ended
|
ZRE142 JPP LE | — | |
| 87106-12170 note |
Servo Sub-assy, Damper(FOR AIRMIX)
2010-12 → 2011-02
ended
|
ZRE142 JPP LE | — | |
| 87106-12170 note |
Servo Sub-assy, Damper(FOR AIRMIX)
2011-02 → 2013-08
ended
|
ZRE142 JPP LE | — | |
| 87106J — Servo Sub-assy, Damper(FOR MODE) | ||||
| 87106-42100 note |
Servo Sub-assy, Damper(FOR MODE)
2007-12 → 2010-12
ended
|
ZRE142 JPP LE | — | |
| 87106-42100 note |
Servo Sub-assy, Damper(FOR MODE)
2007-12 → 2010-12
ended
|
ZRE142 JPP LE | — | |
| 87106-42100 note |
Servo Sub-assy, Damper(FOR MODE)
2010-12 → 2011-02
ended
|
ZRE142 JPP LE | — | |
| 87106-42100 note |
Servo Sub-assy, Damper(FOR MODE)
2011-02 → 2013-08
ended
|
ZRE142 JPP LE | — | |
| 87106N — Servo Sub-assy, Damper(FOR RECIRCULATION) | ||||
| 87106-42130 |
Servo Sub-assy, Damper(FOR RECIRCULATION)
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 87106-42140 note |
Servo Sub-assy, Damper(FOR RECIRCULATION)
2007-12 → 2010-12
ended
|
ZRE142 JPP LE | — | |
| 87106-42140 note |
Servo Sub-assy, Damper(FOR RECIRCULATION)
2007-12 → 2010-12
ended
|
ZRE142 JPP LE | — | |
| 87106-42130 |
Servo Sub-assy, Damper(FOR RECIRCULATION)
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 87106-42140 note |
Servo Sub-assy, Damper(FOR RECIRCULATION)
2010-12 → 2011-02
ended
|
ZRE142 JPP LE | — | |
| 87106-42140 note |
Servo Sub-assy, Damper(FOR RECIRCULATION)
2011-02 → 2011-12
ended
|
ZRE142 JPP LE | — | |
| 87106-47130 note |
Servo Sub-assy, Damper(FOR RECIRCULATION)
2011-12 → 2013-08
ended
|
ZRE142 JPP LE | — | |
| 87107A — Unit Sub-assy, Heater Radiator | ||||
| 87107-42170 |
Unit Sub-assy, Heater Radiator
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 87107-42170 |
Unit Sub-assy, Heater Radiator
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 87114B — Cover, Heater | ||||
| 87114-12080 |
Cover, Heater
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 87114-12080 note |
Cover, Heater
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 87114-12080 |
Cover, Heater
2010-12 → 2011-02
ended
|
ZRE142 JPP | — | |
| 87114-12080 note |
Cover, Heater
2010-12 → 2011-02
ended
|
ZRE142 JPP | — | |
| 87114-12080 note |
Cover, Heater
2011-02 → 2013-08
ended
|
ZRE142 JPP | — | |
| 87130D — Blower Assy | ||||
| 87130-12410 note |
Blower Assy
2007-12 → 2008-05
ended
|
ZRE142 JPP LE | — | |
| 87130-12411 note |
Blower Assy
2008-06 → 2010-12
ended
|
ZRE142 JPP LE | — | |
| 87130-12420 note |
Blower Assy
2007-12 → 2008-05
ended
|
ZRE142 JPP LE | — | |
| 87130-12421 note |
Blower Assy
2008-06 → 2010-12
ended
|
ZRE142 JPP LE | — | |
| 87130-12550 |
Blower Assy
2007-12 → 2008-06
ended
|
ZRE142 JPP | — | |
| 87130-12551 |
Blower Assy
2008-06 → 2010-12
ended
|
ZRE142 JPP | — | |
| 87130-12560 note |
Blower Assy
2007-12 → 2008-05
ended
|
ZRE142 JPP | — | |
| 87130-12561 note |
Blower Assy
2008-06 → 2010-12
ended
|
ZRE142 JPP | — | |
| 87130-12421 note |
Blower Assy
2010-12 → 2011-02
ended
|
ZRE142 JPP LE | — | |
| 87130-12421 note |
Blower Assy
2011-02 → 2013-08
ended
|
ZRE142 JPP LE | — | |
| 87130-12551 |
Blower Assy
2010-12 → 2011-02
ended
|
ZRE142 JPP | — | |
| 87130-12551 note |
Blower Assy
2011-02 → 2013-08
ended
|
ZRE142 JPP | — | |
| 87130-12561 note |
Blower Assy
2010-12 → 2011-02
ended
|
ZRE142 JPP | — | |
| 87130-12561 |
Blower Assy
2011-02 → 2013-08
ended
|
ZRE142 JPP | — | |
| 87139C — Filter, Clean Air | ||||
| 87139-50060 note |
Filter, Clean Air
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 87139-52020 note |
Filter, Clean Air
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 87139-50060 note |
Filter, Clean Air
2010-12 → 2012-04
ended
|
ZRE142 JPP | — | |
| 87139-50100 note |
Filter, Clean Air
2012-05 → 2013-08
ended
|
ZRE142 JPP | — | |
| 87139-52020 note |
Filter, Clean Air
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 87710G — Quick Heater Assy | ||||
| 87710-12020 note |
Quick Heater Assy
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 87710-12020 note |
Quick Heater Assy
2007-12 → 2010-12
ended
|
ZRE142 JPP LE | — | |
| 87710-12020 note |
Quick Heater Assy
2010-12 → 2011-02
ended
|
ZRE142 JPP LE | — | |
| 87710-12020 note |
Quick Heater Assy
2010-12 → 2011-02
ended
|
ZRE142 JPP | — | |
| 87710-12020 |
Quick Heater Assy
2011-02 → 2013-08
ended
|
ZRE142 JPP | — | |
| 88501 — Evaporator Sub-assy, Cooler, NO.1 | ||||
| 88501-26210 |
Evaporator Sub-assy, Cooler, NO.1
2007-12 → 2008-05
ended
|
ZRE142 JPP | — | |
| 88501-26211 |
Evaporator Sub-assy, Cooler, NO.1
2008-06 → 2010-09
ended
|
ZRE142 JPP | — | |
| 88501-72020 |
Evaporator Sub-assy, Cooler, NO.1
2010-10 → 2010-12
ended
|
ZRE142 JPP | — | |
| 88501-72020 |
Evaporator Sub-assy, Cooler, NO.1
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 88501G — O-ring, Cooler Evaporator NO.1(SUCTION) | ||||
| 90099-14121 note |
O-ring, Cooler Evaporator NO.1(SUCTION)
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 90099-14121 note |
O-ring, Cooler Evaporator NO.1(SUCTION)
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 88501K — O-ring, Cooler Evaporator NO.1(LIQUID) | ||||
| 90099-14120 note |
O-ring, Cooler Evaporator NO.1(LIQUID)
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 90099-14120 note |
O-ring, Cooler Evaporator NO.1(LIQUID)
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 88515 — Valve, Cooler Expansion | ||||
| 88515-12100 |
Valve, Cooler Expansion
2010-05 → 2010-12
ended
|
ZRE142 JPP | — | |
| 88515-26070 |
Valve, Cooler Expansion
2009-02 → 2010-05
ended
|
ZRE142 JPP | — | |
| 88515-42090 |
Valve, Cooler Expansion
2007-12 → 2009-01
ended
|
ZRE142 JPP | — | |
| 88515-12100 |
Valve, Cooler Expansion
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 88539J — Hose, Drain Cooler | ||||
| 88539-12200 |
Hose, Drain Cooler
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 88539-12200 |
Hose, Drain Cooler
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 88548B — Case, Air Filter | ||||
| 88548-42020 |
Case, Air Filter
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 88548-42020 |
Case, Air Filter
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 88625 — Thermistor, Cooler, NO.1 | ||||
| 88625-26090 |
Thermistor, Cooler, NO.1
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 88625-26090 |
Thermistor, Cooler, NO.1
2010-12 → 2013-08
ended
|
ZRE142 JPP | — | |
| 88650N — Amplifier Assy, Air Conditioner | ||||
| 88650-12A80 |
Amplifier Assy, Air Conditioner
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 88650-12B40 note |
Amplifier Assy, Air Conditioner
2007-12 → 2010-12
ended
|
ZRE142 JPP LE | — | |
| 88650-12D80 note |
Amplifier Assy, Air Conditioner
2007-12 → 2010-12
ended
|
ZRE142 JPP | — | |
| 88650-12D90 note |
Amplifier Assy, Air Conditioner
2007-12 → 2010-12
ended
|
ZRE142 JPP LE | — | |
| 88650-12F10 |
Amplifier Assy, Air Conditioner
2010-12 → 2011-02
ended
|
ZRE142 JPP | — | |
| 88650-12F10 note |
Amplifier Assy, Air Conditioner
2011-02 → 2013-08
ended
|
ZRE142 JPP | — | |
| 88650-12F20 note |
Amplifier Assy, Air Conditioner
2010-12 → 2011-02
ended
|
ZRE142 JPP | — | |
| 88650-12F20 |
Amplifier Assy, Air Conditioner
2011-02 → 2013-08
ended
|
ZRE142 JPP | — | |
| 88650-12F40 note |
Amplifier Assy, Air Conditioner
2010-12 → 2011-02
ended
|
ZRE142 JPP LE | — | |
| 88650-12F40 note |
Amplifier Assy, Air Conditioner
2011-02 → 2013-08
ended
|
ZRE142 JPP LE | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
