Heating & Air Conditioning - Compressor

6 part groups · 2 illustrations

Illustrations

Figure 87D695

87D695 2013-08 → —

Figure 87D696A

87D696A 2016-08 → —

Part groups

PNC	Description
88310	Compressor Assy, W/Pulley
88320	Compressor Assy, Cooler
88330A	Washer (FOR MAGNET CLUTCH)
88410	Clutch Assy, Magnet
88446D	Bolt, Cooler
88688K	Bracket, Cooler Compressor

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
