Toyota Corolla Hatchback
2018-06 → present · chassis MZEA12 · catalogue 165430 · United States
Supported model
Data version 2022-09
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 12211 — Case, Ventilation, NO.1 | ||||
| 12211-24010 |
Case, Ventilation, NO.1
2018-06 → 2022-08
ended
|
M20AFKS MZEA12 | — | |
| 12211-24020 |
Case, Ventilation, NO.1
2022-09 → 2023-11
ended
|
M20AFKS MZEA12 | — | |
| 12262 — Hose, Ventilation, NO.2 | ||||
| 12262-24020 |
Hose, Ventilation, NO.2
2018-06 → 2022-09
ended
|
M20AFKS MZEA12 CVT | — | |
| 12262-24020 |
Hose, Ventilation, NO.2
2018-06 → —
|
M20AFKS MZEA12 6F | — | |
| 12262-24020 |
Hose, Ventilation, NO.2
2022-09 → —
|
M20AFKS MZEA12 | — | |
| 12262A — Clip(FOR VENTILATION HOSE NO.2) | ||||
| 90467-21004 |
Clip(FOR VENTILATION HOSE NO.2)
2018-06 → 2022-09
ended
|
M20AFKS MZEA12 CVT | — | |
| 90467-21004 |
Clip(FOR VENTILATION HOSE NO.2)
2018-06 → —
|
M20AFKS MZEA12 6F | — | |
| 90467-21004 |
Clip(FOR VENTILATION HOSE NO.2)
2022-09 → —
|
M20AFKS MZEA12 | — | |
| 12273E — Gasket(FOR VENTILATION CASE) | ||||
| 12273-24010 |
Gasket(FOR VENTILATION CASE)
2018-06 → 2022-09
ended
|
M20AFKS MZEA12 CVT | — | |
| 12273-24010 |
Gasket(FOR VENTILATION CASE)
2018-06 → —
|
M20AFKS MZEA12 6F | — | |
| 12273-24010 |
Gasket(FOR VENTILATION CASE)
2022-09 → 2023-11
ended
|
M20AFKS MZEA12 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
