Toyota Corolla Hatchback
2018-06 → present · chassis MZEA12 · catalogue 165430 · United States
Supported model
Data version 2022-09
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 19100P — Plug, Spark | ||||
| 90919-01297 note |
Plug, Spark
2018-06 → 2022-09
ended
|
M20AFKS MZEA12 CVT | — | |
| 90919-01297 note |
Plug, Spark
2018-06 → —
|
M20AFKS MZEA12 6F | — | |
| 90919-01297 note |
Plug, Spark
2022-09 → —
|
M20AFKS MZEA12 | — | |
| 19500 — Coil Assy, Ignition | ||||
| 90919-02276 |
Coil Assy, Ignition
2018-06 → 2022-09
ended
|
M20AFKS MZEA12 CVT | — | |
| 90919-02276 |
Coil Assy, Ignition
2018-06 → —
|
M20AFKS MZEA12 6F | — | |
| 90919-02276 |
Coil Assy, Ignition
2022-09 → —
|
M20AFKS MZEA12 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
