Toyota Corolla Hatchback
2018-06 → present · chassis MZEA12 · catalogue 165430 · United States
Supported model
Data version 2022-09
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 74404A — Clamp Sub-assy, Battery | ||||
| 74404-12560 |
Clamp Sub-assy, Battery
2018-06 → 2021-07
ended
|
MZEA12 | — | |
| 74404-12600 |
Clamp Sub-assy, Battery
2021-07 → 2022-09
ended
|
MZEA12 CVT | — | |
| 74404-12600 |
Clamp Sub-assy, Battery
2021-07 → —
|
MZEA12 6F | — | |
| 74404-12600 |
Clamp Sub-assy, Battery
2022-09 → —
|
MZEA12 | — | |
| 74405 — Clamp Sub-assy, Battery, NO.2 | ||||
| 74405-76021 |
Clamp Sub-assy, Battery, NO.2
2018-06 → 2022-09
ended
|
MZEA12 CVT | — | |
| 74405-76021 |
Clamp Sub-assy, Battery, NO.2
2018-06 → —
|
MZEA12 6F | — | |
| 74405-76021 |
Clamp Sub-assy, Battery, NO.2
2022-09 → —
|
MZEA12 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
