Toyota Corolla Hatchback
2018-06 → present · chassis MZEA12 · catalogue 165430 · United States
Supported model
Data version 2022-09
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 82620A — Block Assy, Fusible Link | ||||
| 82620-12310 |
Block Assy, Fusible Link
2018-06 → 2022-09
ended
|
MZEA12 CVT | — | |
| 82620-12310 |
Block Assy, Fusible Link
2018-06 → —
|
MZEA12 6F | — | |
| 82620-12310 |
Block Assy, Fusible Link
2022-09 → —
|
MZEA12 | — | |
| 82621A — Cover, Fusible Link | ||||
| 82621-12040 |
Cover, Fusible Link
2018-06 → 2022-09
ended
|
MZEA12 CVT | — | |
| 82621-12040 |
Cover, Fusible Link
2018-06 → —
|
MZEA12 6F | — | |
| 82621-12040 |
Cover, Fusible Link
2022-09 → —
|
MZEA12 | — | |
| 89257 — Computer, Cooling Fan | ||||
| 89257-K0020 |
Computer, Cooling Fan
2022-09 → —
|
MZEA12 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
