Toyota Corolla Hatchback
2018-06 → present · chassis MZEA12 · catalogue 165430 · United States
Supported model
Data version 2022-09
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 89413D — Ring, O(FOR TRANSMISSION REVOLUTION SENSOR) | ||||
| 90301-11008 |
Ring, O(FOR TRANSMISSION REVOLUTION SENSOR)
2018-06 → 2022-08
ended
|
MZEA12 6F | — | |
| 90301-11008 |
Ring, O(FOR TRANSMISSION REVOLUTION SENSOR)
2021-07 → 2022-08
ended
|
MZEA12 CVT | — | |
| 90301-11008 |
Ring, O(FOR TRANSMISSION REVOLUTION SENSOR)
2018-06 → 2021-06
ended
|
MZEA12 CVT | — | |
| 90301-11008 |
Ring, O(FOR TRANSMISSION REVOLUTION SENSOR)
2022-09 → 2023-08
ended
|
MZEA12 | — | |
| 90301-11008 note |
Ring, O(FOR TRANSMISSION REVOLUTION SENSOR)
2023-03 → 2023-08
ended
|
MZEA12 | — | |
| 90301-11008 |
Ring, O(FOR TRANSMISSION REVOLUTION SENSOR)
2023-08 → —
|
MZEA12 | — | |
| 89413M — Sensor, Transmission Revolution, (NOUT) | ||||
| 89413-12010 |
Sensor, Transmission Revolution, (NOUT)
2018-06 → 2022-08
ended
|
MZEA12 CVT | — | |
| 89413-12010 |
Sensor, Transmission Revolution, (NOUT)
2022-09 → 2023-08
ended
|
MZEA12 | — | |
| 89413N — Sensor, Transmission Revolution, (NT) | ||||
| 89413-12010 |
Sensor, Transmission Revolution, (NT)
2018-06 → 2022-08
ended
|
MZEA12 CVT | — | |
| 89413-12010 |
Sensor, Transmission Revolution, (NT)
2022-09 → —
|
MZEA12 | — | |
| 89413S — Sensor, Transmission Revolution (NC) | ||||
| 89413-11020 |
Sensor, Transmission Revolution (NC)
2018-06 → 2018-08
ended
|
MZEA12 CVT | — | |
| 89413-11021 |
Sensor, Transmission Revolution (NC)
2018-08 → 2022-08
ended
|
MZEA12 CVT | — | |
| 89413-11021 |
Sensor, Transmission Revolution (NC)
2022-09 → —
|
MZEA12 | — | |
| 89413T — Sensor, Transmission Revolution (NSS) | ||||
| 89413-12010 |
Sensor, Transmission Revolution (NSS)
2018-06 → 2022-08
ended
|
MZEA12 CVT | — | |
| 89413-12010 |
Sensor, Transmission Revolution (NSS)
2022-09 → —
|
MZEA12 | — | |
| 89637K — Sensor, Oil Pressure | ||||
| 89637-12040 |
Sensor, Oil Pressure
2018-06 → 2022-08
ended
|
MZEA12 CVT | — | |
| 89637-12040 |
Sensor, Oil Pressure
2022-09 → —
|
MZEA12 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
