Toyota GR Corolla
2022-10 → present · chassis GZEA14 · catalogue 16E410 · United States
Supported model
Data version 2024-09
Deck Board & Deck Trim Cover
19 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 53655 | Brace, Rear Suspension, Upper Center |
| 53657 | Bracket, Rear Suspension Brace, NO.1 |
| 58410B | Board Assy, Deck |
| 58415E | Board, Rear Floor, NO.1 |
| 58455F | Panel, Rear Floor Board, NO.1 |
| 58460J | Striker Assy, Luggage Hold Belt |
| 62627D | Cover, Side Trim, RH |
| 62628A | Cover, Side Trim, LH |
| 64306 | Suspender Sub-assy, Package Tray Trim |
| 64330D | Panel Assy, Package Tray Trim |
| 64376 | Spacer, Package Tray Trim, NO.2 |
| 64716D | Cover, Deck Trim, Rear |
| 64716E | Clip(FOR DECK TRIM REAR COVER) |
| 64726B | Clip, Deck Rear Trim |
| 64730B | Panel Assy, Deck Trim Side, RH |
| 64740C | Panel Assy, Deck Trim Side, LH |
| 64750F | Clip(FOR DECK SIDE TRIM PANEL) |
| 64777J | Cushion, Spare Wheel |
| 64779B | Stopper, Spare Wheel Cover |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
