Toyota Prius Prime(PHV)
2016-09 → 2022-11 · chassis ZVW52 · catalogue 224430 · United States
Supported model
Data version 2023-12
Side Member
83 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 55168 | Bracket, Front Fender Mounting, RH |
| 55169A | Bracket, Front Fender Mounting, LH |
| 58745 | Protector, Quarter Panel, Front RH |
| 58746 | Protector, Quarter Panel, Front LH |
| 61013C | Panel Sub-assy, Side, Inner RH |
| 61014C | Panel Sub-assy, Side, Inner LH |
| 61017A | Member Sub-assy, Side, Rear RH |
| 61018A | Member Sub-assy, Side, Rear LH |
| 61023B | Pillar Sub-assy, Front Body, Inner RH |
| 61024B | Pillar Sub-assy, Front Body, Inner LH |
| 61037A | Reinforcement Sub-assy, Center Body Pillar, RH |
| 61038A | Reinforcement Sub-assy, Center Body Pillar, LH |
| 61103G | Gusset Sub-assy, Front Body Pillar, Lower RH |
| 61104G | Gusset Sub-assy, Front Body Pillar, Lower LH |
| 61108D | Reinforcement Sub-assy, Front Pillar, Lower RH |
| 61109C | Reinforcement Sub-assy, Front Pillar, Lower LH |
| 61141B | Gusset, Front Body Pillar, Upper RH |
| 61142B | Gusset, Front Body Pillar, Upper LH |
| 61158A | Extension, Front Piller, Lower RH |
| 61159K | Extension, Front Piller, Lower LH |
| 61171 | Retainer, Front Pillar, Lower Inner RH |
| 61172A | Retainer, Front Pillar, Lower Inner LH |
| 61201 | Rail Sub-assy, Roof Side, RH |
| 61202 | Rail Sub-assy, Roof Side, LH |
| 61203 | Rail Sub-assy, Roof Side, Inner RH |
| 61204 | Rail Sub-assy, Roof Side, Inner LH |
| 61211C | Rail, Roof Side, RH |
| 61212C | Rail, Roof Side, LH |
| 61247B | Reinforcement, Roof Side Rail, Inner RH |
| 61248B | Reinforcement, Roof Side Rail, Inner LH |
| 61305 | Reinforce Sub-assy, Center Body Pillar, Lower RH |
| 61306 | Reinforce Sub-assy, Center Body Pillar, Lower LH |
| 61311B | Pillar, Center Body, Outer RH |
| 61312B | Pillar, Center Body, Outer LH |
| 61345B | Pillar, Center Body, Inner Lower RH |
| 61346B | Pillar, Center Body, Inner Lower LH |
| 61401F | Reinforcement Sub-assy, Rocker Panel, RH |
| 61402H | Reinforcement Sub-assy, Rocker Panel, LH |
| 61403C | Reinforce Sub-assy, Rocker, Outer RH |
| 61404E | Reinforce Sub-assy, Rocker, Outer LH |
| 61601B | Panel Sub-assy, Quarter, RH |
| 61602C | Panel Sub-assy, Quarter, LH |
| 61607H | Panel Sub-assy, Quarter Wheel House, Inner RH |
| 61608H | Panel Sub-assy, Quarter Wheel House, Inner LH |
| 61621D | Trough, Back Door Opening, RH |
| 61622D | Trough, Back Door Opening, LH |
| 61623D | Extension, Quarter Panel, Front RH |
| 61624D | Extension, Quarter Panel, Front LH |
| 61625G | Extension, Quarter Panel, Rear RH |
| 61626G | Extension, Quarter Panel, Rear LH |
| 61631A | Panel, Quarter Wheel House, Outer RH |
| 61632A | Panel, Quarter Wheel House, Outer LH |
| 61673B | Reinforcement, Quarter Wheel House, Inner RH |
| 61674B | Reinforcement, Quarter Wheel House, Inner LH |
| 61707L | Panel Sub-assy, Roof Side, Inner Front RH |
| 61708G | Panel Sub-assy, Roof Side, Inner Front LH |
| 61711 | Panel, Roof Side, Outer RH |
| 61712 | Panel, Roof Side, Outer LH |
| 61713A | Extension, Roof Side, Outer RH |
| 61714A | Extension, Roof Side, Outer LH |
| 61715B | Extension, Roof Side, Inner Front RH |
| 61716B | Extension, Roof Side, Inner Front LH |
| 61733A | Panel, Roof Side, Inner Front RH |
| 61734A | Panel, Roof Side, Inner Front LH |
| 61737D | Reinforcement, Roof Side, Inner RH |
| 61738D | Reinforcement, Roof Side, Inner LH |
| 61743A | Reinforcement, Back Door Opening Side, RH |
| 61744A | Reinforcement, Back Door Opening Side, LH |
| 61766B | Reinforcement, Belt Anchor TO Roof Side, Inner RH |
| 61767B | Reinforcement, Belt Anchor TO Roof Side, Inner LH |
| 61777D | Retainer, Back Door Side Stopper, RH |
| 61778J | Retainer, Back Door Side Stopper, LH |
| 62611F | Insulator, Quarter Wheel House, RH |
| 62612E | Insulator, Quarter Wheel House, LH |
| 65563B | Plate, Side Panel Rear End Post, Lower RH |
| 65564A | Plate, Side Panel Rear End Post, Lower LH |
| 65637 | Liner, Rear Wheel House, RH |
| 65637C | Clip, Rear Wheel House Liner |
| 65638 | Liner, Rear Wheel House, LH |
| 65638C | Clip, Rear Wheel House Liner |
| 68981A | Retainer, Back Door Stay, RH |
| 68982A | Retainer, Back Door Stay, LH |
| 81496G | Guide, Rear Combination Lamp |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
