Toyota Prius Prime(PHV)
2016-09 → 2022-11 · chassis ZVW52 · catalogue 224430 · United States
Supported model
Data version 2023-12
Back Door Panel & Glass
33 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 62785F | Spacer, Back Door Glass |
| 62785P | Spacer, Quarter Window Glass |
| 62785Q | Spacer, Quarter Window Glass, NO.2 |
| 64790B | Panel Assy, Back Door Trim, Upper |
| 64818C | Spacer, Back Window Glass, NO.1 |
| 64818D | Spacer, Back Window Glass, NO.3 |
| 64819B | Spacer, Back Window Glass, NO.2 |
| 64819D | Spacer, Back Window Glass, NO.4 |
| 64821 | Glass, Back Window Fix |
| 66311M | Hook, Rope |
| 67005 | Panel Sub-assy, Back Door |
| 67005B | Cushion(FOR BACK DOOR PANEL) |
| 67281B | Stopper, Back Door, Lower |
| 67282F | Stopper, Back Door, Lwr LH |
| 67293 | Cushion, Back Door Lower Stopper |
| 67750 | Board Assy, Back Door Trim |
| 67750A | Clip(FOR BACK DOOR TRIM) |
| 67751 | Board, Back Door Trim |
| 67751A | Clip(FOR BACK DOOR TRIM BOARD) |
| 67751B | Retainer(FOR BACK DOOR TRIM BOARD) |
| 67759A | Clip(FOR BACK DOOR TRIM BOARD) |
| 67761A | Cover, Back Door Trim |
| 67881A | Weatherstrip, Back Door |
| 68131 | Glass, Back Door |
| 68294A | Dam, Back Door Glass Adhesive |
| 68294D | Dam, Back Door Glass Adhesive, NO.2 |
| 75129C | Cushion, Rear Licence Plate |
| 75571E | Moulding, Back Window, Outside Upper RH |
| 75572E | Moulding, Back Window, Outside Upper LH |
| 75575J | Moulding, Back Window, Outside Lower RH |
| 75576B | Moulding, Back Window, Outside Lower LH |
| 76831A | Cover, Back Door Finish Panel, RH |
| 76835A | Protector, Back Door Finish Panel, NO.1 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
