Toyota Lexus CT200H
2010-12 → 2021-08 · chassis ZWA10 · catalogue 232410 · United States
Supported model
Data version 2023-12
Navigation & Front Monitor Display
37 part groups · 7 illustrations
Part groups
| PNC | Description |
|---|---|
| 81620B | Cover Assy LH |
| 82219F | Wire, Sensor |
| 82286B | Wire, Earth, NO.2 |
| 84013D | Panel Sub-assy, Integration |
| 84781 | Switch, Remote Operation |
| 84782 | Board, Remote Operation |
| 84811E | Knob, Switch |
| 86012A | Parts Set, Radio Setting |
| 86101H | Cord Sub-assy, Antenna |
| 86101M | Cord Sub-assy, Antenna |
| 86104A | Controller Sub-assy, Multi-display |
| 86111 | Multi-display |
| 86117 | Bracket, Multi-display Controller, A |
| 86118 | Bracket, Multi-display Controler, B |
| 86271 | Disc, Disc Player |
| 86271L | Hard Disc |
| 86274D | Bracket, Disc Player |
| 86274F | Bracket, Disc Player, NO.2 |
| 86274G | Bracket, Disc Player, NO.3 |
| 86274K | Bracket, Disc Player, NO.4 |
| 86274N | Bracket, Disc Player, NO.5 |
| 86421 | Board, Navigation Module |
| 86431 | Display, Display & Navigation Module |
| 86431A | Board, Display Module |
| 86453 | Wire, Multi-media Module |
| 86456 | Cover, Multi-media Module |
| 86457 | Bracket, Multi-media Module NO.1 |
| 86457A | Bracket, Multi-media Module NO.2 |
| 86457B | Bracket, Multi-media Module NO.3 |
| 86730A | Microphone Assy, Telephone |
| 86804A | Sub-assy, Navigation Computer |
| 86808 | Cord Sub-assy, Navigation Antenna, NO.1 |
| 86842 | Wire, Navigation, NO.1 |
| 86842J | Wire, Navigation, NO.2 |
| 86860 | Antenna Assy, Navigation |
| 86862 | Bracket, Navigation Antenna |
| 89279Q | Cover |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
