Toyota Lexus IS300
2000-05 → 2005-07 · chassis JCE10 · catalogue 242410 · United States
Discontinued model
Data version 2006-02
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 52114A — Bracket, Front Bumper Extension Mounting | ||||
| 52114-53020 |
Bracket, Front Bumper Extension Mounting
2000-05 → 2001-07
ended
|
JCE10 | — | |
| 52114-53020 |
Bracket, Front Bumper Extension Mounting
2001-07 → —
|
JCE10 SED | — | |
| 52114-53050 |
Bracket, Front Bumper Extension Mounting
2001-07 → —
|
JCE10 WG | — | |
| 52115D — Support, Front Bumper Side, NO.2 RH | ||||
| 52115-53010 |
Support, Front Bumper Side, NO.2 RH
2000-05 → 2001-07
ended
|
JCE10 | — | |
| 52115-53010 |
Support, Front Bumper Side, NO.2 RH
2001-07 → —
|
JCE10 | — | |
| 52116D — Support, Front Bumper Side, NO.2 LH | ||||
| 52116-53010 |
Support, Front Bumper Side, NO.2 LH
2000-05 → 2001-07
ended
|
JCE10 | — | |
| 52116-53010 |
Support, Front Bumper Side, NO.2 LH
2001-07 → —
|
JCE10 | — | |
| 52119A — Cover, Front Bumper | ||||
| 52119-53903 |
Cover, Front Bumper
2000-05 → 2001-07
ended
|
JCE10 | — | |
| 52119-53904 note |
Cover, Front Bumper
2000-05 → 2001-07
ended
|
JCE10 | — | |
| 52119-53903 |
Cover, Front Bumper
2001-07 → —
|
JCE10 SED | — | |
| 52119-53904 note |
Cover, Front Bumper
2001-07 → —
|
JCE10 SED | — | |
| 52119-53907 |
Cover, Front Bumper
2001-07 → —
|
JCE10 WG | — | |
| 52119-53908 note |
Cover, Front Bumper
2001-07 → —
|
JCE10 WG | — | |
| 52127D — Cover, Front Bumper Hole, RH | ||||
| 52127-53010 |
Cover, Front Bumper Hole, RH
2000-05 → 2001-07
ended
|
JCE10 | — | |
| 52127-53010 |
Cover, Front Bumper Hole, RH
2001-07 → —
|
JCE10 SED | — | |
| 52127-53020 |
Cover, Front Bumper Hole, RH
2001-07 → —
|
JCE10 WG | — | |
| 52128B — Cover, Front Bumper Hole, LH | ||||
| 52128-53010 |
Cover, Front Bumper Hole, LH
2000-05 → 2001-07
ended
|
JCE10 | — | |
| 52128-53010 |
Cover, Front Bumper Hole, LH
2001-07 → —
|
JCE10 SED | — | |
| 52128-53020 |
Cover, Front Bumper Hole, LH
2001-07 → —
|
JCE10 WG | — | |
| 52131A — Reinforcement, Front Bumper | ||||
| 52131-53030 |
Reinforcement, Front Bumper
2000-05 → 2001-07
ended
|
JCE10 | — | |
| 52131-53030 |
Reinforcement, Front Bumper
2001-07 → —
|
JCE10 | — | |
| 52132A — Reinforcement, Front Bumper, NO.2 | ||||
| 52132-53010 |
Reinforcement, Front Bumper, NO.2
2000-05 → 2001-07
ended
|
JCE10 | — | |
| 52132-53010 |
Reinforcement, Front Bumper, NO.2
2001-07 → —
|
JCE10 | — | |
| 52133C — Reinforcement, Front Bumper Bar, RH | ||||
| 52133-53010 |
Reinforcement, Front Bumper Bar, RH
2000-05 → 2001-07
ended
|
JCE10 | — | |
| 52133-53010 |
Reinforcement, Front Bumper Bar, RH
2001-07 → —
|
JCE10 | — | |
| 52134C — Reinforcement, Front Bumper Bar, LH | ||||
| 52134-53010 |
Reinforcement, Front Bumper Bar, LH
2000-05 → 2001-07
ended
|
JCE10 | — | |
| 52134-53010 |
Reinforcement, Front Bumper Bar, LH
2001-07 → —
|
JCE10 | — | |
| 52541 — Protector, Front Bumper | ||||
| 52541-51010 |
Protector, Front Bumper
2000-05 → 2001-07
ended
|
JCE10 | — | |
| 52541-51010 |
Protector, Front Bumper
2001-07 → —
|
JCE10 | — | |
| 52611 — Absorber, Front Bumper Energy | ||||
| 52611-53020 |
Absorber, Front Bumper Energy
2000-05 → 2001-07
ended
|
JCE10 | — | |
| 52611-53020 |
Absorber, Front Bumper Energy
2001-07 → —
|
JCE10 SED | — | |
| 52611-53040 |
Absorber, Front Bumper Energy
2001-07 → —
|
JCE10 WG | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
