Toyota Corona
1973-08 → 1978-08 · chassis RT10#,11# · catalogue 261430 · United States
Discontinued model
Data version 1985-04
Switch & Relay & Computer
94 part groups · 9 illustrations
Part groups
| PNC | Description |
|---|---|
| 27700 | Regulator Assy, Generator |
| 27790 | Relay Assy, Charge Lamp |
| 28300 | Relay Assy, Starter |
| 28301 | Relay Assy, Fuel Pump |
| 28371 | Relay, Ignition, NO.1 |
| 28371A | Relay, Bulb Check |
| 81944 | Cord, Optical Fiber |
| 81980 | Flasher Assy, Turn Signal |
| 82600 | Block Assy, Fuse |
| 82600F | Fuse, Fuse Block |
| 82611 | Cover, Fuse Block |
| 82612 | Insulator, Fuse Block Terminal |
| 82614 | Lever, Fuse |
| 83320 | Gage Assy, Fuel Sender |
| 83361 | Gasket, Fuel Sender Gage |
| 83390 | Switch Assy, Vacuum Warning |
| 83391 | Switch, Vacuum |
| 83399 | Bracket, Vacuum Switch |
| 83420 | Gage Assy, Water Temperature Sender |
| 83530 | Switch Assy, Oil Pressure (FOR ENGINE) |
| 83540 | Switch Assy, Brake Warning (FOR TANDEM MASTER CYLINDER) |
| 84052 | Switch Assy, Un-lock Warning |
| 84095 | Bracket Sub-assy, Hand Brake Signal Switch |
| 84110 | Switch Assy, Light Control, NO.1 |
| 84118 | Knob, Light Control Rheostat |
| 84119 | Rheostat, Light Control |
| 84119A | Bolt OR Nut, Rheostat Control Set |
| 84210 | Switch Assy, Back-up Lamp |
| 84221 | Switch Assy, Differential Valve |
| 84230 | Switch Assy, Courtesy Lamp (FOR ENGINE ROOM) |
| 84230B | Switch Assy, Earth |
| 84231 | Switch Assy, Courtesy Lamp (FOR PARKING BRAKE) |
| 84232 | Switch Assy, Courtesy Lamp (FOR GLOVE BOX) |
| 84232A | Terminal, Courtesy Switch (FOR GLOVE BOX) |
| 84233 | Switch Assy, Courtesy Lamp (FOR FRONT DOOR) |
| 84233B | Cushion, Courtesy Switch (FOR FRONT DOOR) |
| 84234 | Switch Assy, Courtesy Lamp (FOR REAR DOOR) |
| 84234B | Cushion, Courtesy Switch (FOR REAR DOOR) |
| 84235 | Switch Assy, Courtesy Lamp(FOR BACK DOOR) |
| 84237 | Switch Assy, Courtesy Lamp (FOR STEERING UN-LOCK WARNING) |
| 84310 | Switch Assy, Turn Signal |
| 84310K | Switch Kit, Light Control |
| 84312 | Plate, Horn Contact |
| 84340 | Switch Assy, Stop Lamp |
| 84380 | Switch Assy, Brake Warning Test |
| 84450 | Switch Assy, Ignition OR Starter |
| 84540 | Switch Assy, Neutral Start |
| 84650 | Switch Assy, Windshield Wiper |
| 84650A | Bolt OR Nut, Windshield Wiper Switch Set |
| 84651 | Knob, Windshield Wiper Switch |
| 84659 | Bracket, Rear Wiper Switch |
| 84730 | Switch Assy, Heater Blower |
| 84730A | Nut, Heater Blower Switch |
| 84731 | Knob, Heater Blower Switch |
| 84750 | Switch Assy, Seat Belt Warning |
| 84759 | Switch Assy, Interlock Canceling |
| 84790 | Switch Assy, Rear Window Defogger |
| 84790B | Bulb(FOR REAR WINDOW DEFOGGER SWITCH) |
| 85335 | Switch Assy, Washer Level Warning |
| 85336 | Switch Assy, Reserve Tank Level Warning |
| 85430 | Valve, Outer Vent Control |
| 85500 | Lighter Assy, Cigarette |
| 85500B | Bulb, Cigarette Lighter |
| 85533 | Lens, Cigarette Lighter Indicator |
| 85910C | Relay Assy (FOR HEATER BLOWER MOTOR) |
| 85912 | Relay, Defogger |
| 85915 | Relay, Main |
| 85916 | Relay, Light Control |
| 85924 | Relay, Ignition Control |
| 85940 | Relay Assy, Windshield Wiper |
| 85952 | Relay, Level Warning |
| 85958 | Bracket, Main Relay |
| 85990 | Relay OR Computer Assy, Seat Belt Warning |
| 85995A | Bracket, Seat Belt Warning Computer |
| 86530 | Relay Assy, Horn |
| 86680 | Buzzer Assy, Un-lock Warning OR Seat Belt Warning |
| 89371 | Relay, Lamp Failure Indicator |
| 89423 | Sensor, Temperature Detect Egr |
| 89425 | Sensor, Exhaust Gas Temperature |
| 89427 | Switch, Temperature Detect |
| 89437 | Cover, Sensor |
| 89441 | Sensor, Deceleration |
| 89445 | Detector, Maintenance Interval |
| 89448 | Bracket, Maintenance Interval Detector |
| 89491 | Sensor, Engine Oil Level |
| 89491A | Gasket, Engine Oil Level Sensor |
| 89492 | Sensor, Electrolyte Level |
| 89499 | Adapter, Electrolyte Level Sensor |
| 89550 | Computer Assy, Emission Control |
| 89559 | Bracket, Emission Control Computer |
| 89590 | Computer Assy, Condition Indicator |
| 89620 | Igniter Assy |
| 89620A | Diode, Ignition Coil |
| 89629 | Bracket, Igniter Assy |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
