Toyota 86
2016-07 → present · chassis ZN6 · catalogue 264420 · United States
Supported model
Data version 2019-08
Instrument Panel & Glove Compartment
41 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 55039 | Reinforcement Sub-assy,Instrument Panel, Lower |
| 55044B | Panel Sub-assy, Instrument Panel Finish, Upper |
| 55045C | Panel Sub-assy, Instrument Panel Finish, Upper |
| 55061 | Register Sub-assy, Instrument Panel, NO.1 |
| 55062 | Register Sub-assy, Instrument Panel, N0.2 |
| 55302C | Panel Sub-assy, Instrument |
| 55303B | Panel Sub-assy, Instrument, Lower |
| 55309C | Reinforcement Sub-assy, Instrument Panel, Center |
| 55312A | Clip, Instrument Panel |
| 55315A | Spacer, Instrument Panel, NO.1 |
| 55317A | Panel, Instrument Side, RH |
| 55318C | Panel, Instrument Side, LH |
| 55330B | Reinforcement Assy, Instrument Panel |
| 55349A | Cushion, Instrument Panel |
| 55394B | Bolt, Instrument Panel |
| 55394C | Bolt, Instrument Panel |
| 55403 | Hood Sub-assy, Meter |
| 55405B | Panel Sub-assy, Instrument Cluster Finish, Center |
| 55406B | Panel Sub-assy, Instrument Cluster Finish, Lower Center |
| 55408F | Panel Sub-assy, Instrument Panel Speaker, NO.1 |
| 55409F | Panel Sub-assy, Instrument Panel Speaker, NO.2 |
| 55422 | Ornament, Instrument Panel Meter, Upper |
| 55434E | Cap |
| 55435A | Panel, Instrument Panel Finish, End RH |
| 55436A | Panel, Instrument Panel Finish, End LH |
| 55449D | Base, Switch |
| 55474C | Garnish, Instrument Cluster Finish Panel, NO.1 |
| 55475A | Garnish, Instrument Cluster Finish Panel, NO.2 |
| 55503B | Cushion(FOR GLOVE COMPARTMENT) |
| 55510A | Cushion(FOR GLOVE COMPARTMENT DOOR) |
| 55539B | Cover, Spare Switch Hole, NO.2 |
| 55550 | Door Assy, Glove Compartment |
| 55557C | Damper, Glove Compartment Door |
| 55558 | Reinforcement, Glove Compartment Door |
| 55606 | Cover Sub-assy, Instrument Panel Under, NO.1 |
| 55650B | Bezel, Instrument Panel Register |
| 55670A | Register Assy, Instrument Panel, Center |
| 55981 | Garnish, Defroster Nozzle, NO.1 |
| 55982 | Garnish, Defroster Nozzle, NO.2 |
| 55983 | Garnish, Defroster Nozzle, NO.3 |
| 73960A | Airbag Assy, Instrument Panel Passenger W/O Door |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
