Toyota GR 86
2021-11 → present · chassis ZN8 · catalogue 264430 · United States
Supported model
Data version 2024-10
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 19100P — Plug, Spark | ||||
| SU003-04931 |
Plug, Spark
2021-10 → 2022-06
ended
|
FA24 ZN8 | — | |
| SU003-04931 |
Plug, Spark
2022-06 → 2023-12
ended
|
FA24 ZN8 B | — | |
| SU003-04931 |
Plug, Spark
2023-12 → —
|
FA24 ZN8 C | — | |
| SU003-04931 |
Plug, Spark
2024-09 → —
|
FA24 ZN8 D | — | |
| 19500 — Coil Assy, Ignition | ||||
| SU003-08423 |
Coil Assy, Ignition
2021-10 → 2022-06
ended
|
FA24 ZN8 | — | |
| SU003-08423 |
Coil Assy, Ignition
2022-06 → 2023-12
ended
|
FA24 ZN8 B | — | |
| SU003-08423 |
Coil Assy, Ignition
2023-12 → —
|
FA24 ZN8 C | — | |
| SU003-08423 |
Coil Assy, Ignition
2024-09 → —
|
FA24 ZN8 D | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
