Toyota GR 86
2021-11 → present · chassis ZN8 · catalogue 264430 · United States
Supported model
Data version 2024-10
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 35301A — Seal, Oil (FOR FRONT OIL PUMP) | ||||
| SU003-03629 |
Seal, Oil (FOR FRONT OIL PUMP)
2021-10 → 2022-06
ended
|
ZN8 6FC | — | |
| SU003-03629 |
Seal, Oil (FOR FRONT OIL PUMP)
2022-06 → 2023-12
ended
|
ZN8 6FC B | — | |
| SU003-03629 |
Seal, Oil (FOR FRONT OIL PUMP)
2023-12 → —
|
ZN8 6FC C | — | |
| SU003-03629 |
Seal, Oil (FOR FRONT OIL PUMP)
2024-09 → —
|
ZN8 6FC D | — | |
| 35301F — Bolt (FOR FRONT OIL PUMP SETTING) | ||||
| SU003-03465 |
Bolt (FOR FRONT OIL PUMP SETTING)
2021-10 → 2022-06
ended
|
ZN8 6FC | — | |
| SU003-03465 |
Bolt (FOR FRONT OIL PUMP SETTING)
2022-06 → 2023-12
ended
|
ZN8 6FC B | — | |
| SU003-03465 |
Bolt (FOR FRONT OIL PUMP SETTING)
2023-12 → —
|
ZN8 6FC C | — | |
| SU003-03465 |
Bolt (FOR FRONT OIL PUMP SETTING)
2024-09 → —
|
ZN8 6FC D | — | |
| 35310F — Pump Assy, Front Oil | ||||
| SU003-03676 |
Pump Assy, Front Oil
2021-10 → 2022-06
ended
|
ZN8 6FC | — | |
| SU003-03676 |
Pump Assy, Front Oil
2022-06 → 2023-12
ended
|
ZN8 6FC B | — | |
| SU003-03676 |
Pump Assy, Front Oil
2023-12 → —
|
ZN8 6FC C | — | |
| SU003-03676 |
Pump Assy, Front Oil
2024-09 → —
|
ZN8 6FC D | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
