Toyota GR 86
2021-11 → present · chassis ZN8 · catalogue 264430 · United States
Supported model
Data version 2024-10
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 45222G — Clip, Dust Cover | ||||
| SU003-04152 |
Clip, Dust Cover
2021-10 → 2022-06
ended
|
ZN8 | — | |
| SU003-04152 |
Clip, Dust Cover
2022-06 → 2023-12
ended
|
ZN8 B | — | |
| SU003-04152 |
Clip, Dust Cover
2023-12 → —
|
ZN8 C | — | |
| SU003-04152 |
Clip, Dust Cover
2024-09 → —
|
ZN8 D | — | |
| 45260 — Shaft Assy, Steering Intermediate, NO.2 | ||||
| SU003-09868 |
Shaft Assy, Steering Intermediate, NO.2
2021-10 → 2022-06
ended
|
ZN8 | — | |
| SU003-11003 |
Shaft Assy, Steering Intermediate, NO.2
2022-06 → 2023-12
ended
|
ZN8 B | — | |
| SU003-11003 |
Shaft Assy, Steering Intermediate, NO.2
2023-12 → —
|
ZN8 C | — | |
| SU003-11003 |
Shaft Assy, Steering Intermediate, NO.2
2024-09 → —
|
ZN8 D | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
