Toyota Lexus ES350
2006-03 → 2012-06 · chassis GSV40 · catalogue 282480 · United States
Supported model
Data version 2012-04
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
No parts are listed against this drawing
Every callout on it points at hardware this catalogue does not itemise.
