Toyota Camry (NAP)
2006-02 → 2011-09 · chassis ACV40,ASV40,GSV40 · catalogue 283480 · United States
Supported model
Data version 2011-10
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 83320 — Gage Assy, Fuel Sender | ||||
| 83320-06030 |
Gage Assy, Fuel Sender
2006-02 → 2009-03
ended
|
ACV40 NAP | — | |
| 83320-07010 |
Gage Assy, Fuel Sender
2006-02 → 2009-03
ended
|
GSV40 NAP | — | |
| 83320-06030 |
Gage Assy, Fuel Sender
2009-03 → 2011-09
ended
|
ASV40 NAP | — | |
| 83320-07010 |
Gage Assy, Fuel Sender
2009-03 → 2011-09
ended
|
GSV40 NAP | — | |
| 84233 — Switch Assy, Courtesy Lamp (FOR FRONT DOOR) | ||||
| 84231-08030 |
Switch Assy, Courtesy Lamp (FOR FRONT DOOR)
2006-02 → 2009-03
ended
|
ACV40,GSV40 NAP | — | |
| 84231-08030 |
Switch Assy, Courtesy Lamp (FOR FRONT DOOR)
2009-03 → 2011-09
ended
|
ASV40,GSV40 NAP | — | |
| 84234 — Switch Assy, Courtesy Lamp (FOR REAR DOOR) | ||||
| 84231-08030 |
Switch Assy, Courtesy Lamp (FOR REAR DOOR)
2006-02 → 2009-03
ended
|
ACV40,GSV40 NAP | — | |
| 84231-08030 |
Switch Assy, Courtesy Lamp (FOR REAR DOOR)
2009-03 → 2011-09
ended
|
ASV40,GSV40 NAP | — | |
| 84810 — Switch Assy, Power Window Regulator | ||||
| 84810-06030 |
Switch Assy, Power Window Regulator
2006-02 → 2009-03
ended
|
ACV40,GSV40 NAP | — | |
| 84810-06090 |
Switch Assy, Power Window Regulator
2009-03 → 2011-09
ended
|
ASV40,GSV40 NAP | — | |
| 84810D — Switch Assy, Power Window Regulator, Rear | ||||
| 84810-06030 |
Switch Assy, Power Window Regulator, Rear
2006-02 → 2009-03
ended
|
ACV40,GSV40 NAP | — | |
| 84810-06090 |
Switch Assy, Power Window Regulator, Rear
2009-03 → 2011-09
ended
|
ASV40,GSV40 NAP | — | |
| 84820 — Master Switch Assy, Power Window Regulator | ||||
| 84820-06060 |
Master Switch Assy, Power Window Regulator
2006-02 → 2006-08
ended
|
ACV40,GSV40 NAP XLE | — | |
| 84820-06061 |
Master Switch Assy, Power Window Regulator
2006-08 → 2009-03
ended
|
ACV40,GSV40 NAP XLE | — | |
| 84820-06070 |
Master Switch Assy, Power Window Regulator
2006-02 → 2006-08
ended
|
ACV40,GSV40 NAP (LE,SE) | — | |
| 84820-06071 |
Master Switch Assy, Power Window Regulator
2006-08 → 2009-03
ended
|
ACV40,GSV40 NAP (LE,SE) | — | |
| 84040-06030 |
Master Switch Assy, Power Window Regulator
2009-03 → 2011-09
ended
|
ASV40,GSV40 NAP | — | |
| 84840 — Switch Assy, Luggage Compartment Door Opening | ||||
| 84840-20010 note |
Switch Assy, Luggage Compartment Door Opening
2006-02 → 2009-03
ended
|
GSV40 NAP XLE | — | |
| 84840-33090 note |
Switch Assy, Luggage Compartment Door Opening
2009-03 → 2011-09
ended
|
ASV40,GSV40 NAP 6FC (SE,XLE) | — | |
| 84905-33010 note |
Switch Assy, Luggage Compartment Door Opening
2009-03 → 2011-09
ended
|
ASV40,GSV40 NAP 6FC (SE,XLE) | — | |
| 84930 — Switch Assy, Door Control | ||||
| 84930-06020 |
Switch Assy, Door Control
2006-02 → 2006-08
ended
|
ACV40,GSV40 NAP | — | |
| 84930-0C010 |
Switch Assy, Door Control
2006-08 → 2009-03
ended
|
ACV40,GSV40 NAP | — | |
| 84930-0C010 |
Switch Assy, Door Control
2009-03 → 2011-09
ended
|
ASV40,GSV40 NAP | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
