Toyota Camry (JPP)
2001-07 → 2006-01 · chassis ACV30,MCV3# · catalogue 284470 · United States
Discontinued model
Data version 2006-08
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 15601 — Filter Sub-assy, Oil | ||||
| 90080-91210 note |
Filter Sub-assy, Oil
2001-07 → 2004-06
ended
|
2AZFE ACV30 JPP 4FC | — | |
| 90915-10004 |
Filter Sub-assy, Oil
2001-07 → 2004-06
ended
|
2AZFE ACV30 JPP | — | |
| 90915-10004 note |
Filter Sub-assy, Oil
2001-07 → 2004-06
ended
|
2AZFE ACV30 JPP 4FC | — | |
| 90915-20003 |
Filter Sub-assy, Oil
2001-07 → 2003-01
ended
|
1MZFE MCV30 JPP | — | |
| 90915-20003 |
Filter Sub-assy, Oil
2003-01 → 2003-07
ended
|
1MZFE MCV30 JPP SE | — | |
| 90915-20003 |
Filter Sub-assy, Oil
2003-01 → 2004-06
ended
|
3MZFE MCV31 JPP;1MZFE MCV30 +2 | — | |
| 90080-91210 note |
Filter Sub-assy, Oil
2004-06 → 2004-12
ended
|
2AZFE ACV30 JPP 5FC | — | |
| 90915-10004 |
Filter Sub-assy, Oil
2004-06 → —
|
2AZFE ACV30 JPP | — | |
| 90915-10004 note |
Filter Sub-assy, Oil
2004-06 → —
|
2AZFE ACV30 JPP 5FC | — | |
| 90915-20003 |
Filter Sub-assy, Oil
2004-06 → —
|
1MZFE,3MZFE MCV3# JPP | — | |
| 90915-TA002 note |
Filter Sub-assy, Oil
2004-12 → —
|
2AZFE ACV30 JPP 5FC | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
