Toyota Camry (JPP)
2001-07 → 2006-01 · chassis ACV30,MCV3# · catalogue 284470 · United States
Discontinued model
Data version 2006-08
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 28300 — Relay Assy, Starter | ||||
| 28300-10020 |
Relay Assy, Starter
2001-07 → 2004-06
ended
|
2AZFE,1MZFE,3MZFE ACV30,MCV3# JPP | — | |
| 28300-10020 |
Relay Assy, Starter
2004-06 → —
|
2AZFE,1MZFE,3MZFE ACV30,MCV3# JPP | — | |
| 82210J — Fusible Link | ||||
| 90982-08202 note |
Fusible Link
2001-07 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 90982-08246 note |
Fusible Link
2001-07 → 2004-06
ended
|
ACV30 JPP | — | |
| 90982-08274 note |
Fusible Link
2001-07 → 2004-06
ended
|
MCV3# JPP | — | |
| 90982-08280 note |
Fusible Link
2001-07 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 90982-08281 note |
Fusible Link
2001-07 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 90982-08282 note |
Fusible Link
2001-07 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 90982-08202 note |
Fusible Link
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 90982-08246 note |
Fusible Link
2004-06 → —
|
ACV30 JPP | — | |
| 90982-08274 note |
Fusible Link
2004-06 → —
|
MCV3# JPP | — | |
| 90982-08280 note |
Fusible Link
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 90982-08281 note |
Fusible Link
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 90982-08282 note |
Fusible Link
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 82600F — Fuse, Fuse Block | ||||
| 90080-82020 note |
Fuse, Fuse Block
2003-07 → 2004-06
ended
|
MCV30 JPP;ACV30 JPP XLE | — | |
| 90080-82020 note |
Fuse, Fuse Block
2001-07 → 2004-06
ended
|
ACV30,MCV31 JPP (LE,SE) | — | |
| 90080-82020 note |
Fuse, Fuse Block
2001-07 → 2002-08
ended
|
ACV30 JPP XLE | — | |
| 90080-82021 note |
Fuse, Fuse Block
2001-07 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 90080-82022 note |
Fuse, Fuse Block
2001-07 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 90080-82023 note |
Fuse, Fuse Block
2001-07 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 90080-82024 note |
Fuse, Fuse Block
2001-07 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 90080-82031 note |
Fuse, Fuse Block
2001-07 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 90080-82033 note |
Fuse, Fuse Block
2001-07 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 90982-09007 note |
Fuse, Fuse Block
2001-07 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 90982-09008 note |
Fuse, Fuse Block
2001-07 → 2004-06
ended
|
MCV3# JPP | — | |
| 90982-09009 note |
Fuse, Fuse Block
2001-07 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 90982-09010 note |
Fuse, Fuse Block
2001-07 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 90080-82020 note |
Fuse, Fuse Block
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 90080-82021 note |
Fuse, Fuse Block
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 90080-82022 note |
Fuse, Fuse Block
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 90080-82023 note |
Fuse, Fuse Block
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 90080-82024 note |
Fuse, Fuse Block
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 90080-82031 note |
Fuse, Fuse Block
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 90080-82033 note |
Fuse, Fuse Block
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 90982-09007 note |
Fuse, Fuse Block
2004-06 → —
|
MCV3# JPP | — | |
| 90982-09007 note |
Fuse, Fuse Block
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 90982-09008 note |
Fuse, Fuse Block
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 90982-09009 note |
Fuse, Fuse Block
2004-06 → —
|
MCV3# JPP | — | |
| 90982-09009 note |
Fuse, Fuse Block
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 90982-09010 note |
Fuse, Fuse Block
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 82616 — Puller, Fuse | ||||
| 82616-20010 |
Puller, Fuse
2001-07 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 82616-20010 |
Puller, Fuse
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 82642A — Relay, Running Light | ||||
| 90987-02012 |
Relay, Running Light
2001-07 → 2003-04
ended
|
ACV30,MCV30 JPP | — | |
| 90987-02027 |
Relay, Running Light
2003-04 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 90987-02027 |
Relay, Running Light
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 82642C — Relay, Day Time Running Light, NO.2 | ||||
| 90987-04004 |
Relay, Day Time Running Light, NO.2
2001-07 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 90987-04004 |
Relay, Day Time Running Light, NO.2
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 82663A — Cover, Relay Block, Lower, NO.2 | ||||
| 82663-33060 |
Cover, Relay Block, Lower, NO.2
2001-07 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 82663-33060 |
Cover, Relay Block, Lower, NO.2
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 82670G — Block Assy, Engine Room Junction | ||||
| 82720-06040 |
Block Assy, Engine Room Junction
2001-07 → 2003-07
ended
|
ACV30,MCV30 JPP | — | |
| 82720-06041 |
Block Assy, Engine Room Junction
2003-07 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 82720-06041 |
Block Assy, Engine Room Junction
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 82672F — Cover, Junction Block | ||||
| 82672-33220 |
Cover, Junction Block
2001-07 → 2003-07
ended
|
ACV30 JPP | — | |
| 82672-33260 |
Cover, Junction Block
2001-07 → 2003-07
ended
|
MCV30 JPP | — | |
| 82672-33261 |
Cover, Junction Block
2003-07 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 82672-33261 |
Cover, Junction Block
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 82674A — Cover, Junction Block, Lower | ||||
| 82674-33060 |
Cover, Junction Block, Lower
2001-07 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 82674-33060 |
Cover, Junction Block, Lower
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 82695 — Resistor, Daytime Running Light | ||||
| 82695-33010 |
Resistor, Daytime Running Light
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 82695-33020 note |
Resistor, Daytime Running Light
2004-06 → —
|
ACV30 JPP 5F | — | |
| 82741 — Block, Engine Room Relay | ||||
| 82741-33010 |
Block, Engine Room Relay
2001-07 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 82741-33010 |
Block, Engine Room Relay
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 85910C — Relay Assy (FOR HEATER BLOWER MOTOR) | ||||
| 90987-04006 |
Relay Assy (FOR HEATER BLOWER MOTOR)
2001-07 → 2003-07
ended
|
ACV30,MCV30 JPP | — | |
| 90987-04010 |
Relay Assy (FOR HEATER BLOWER MOTOR)
2003-07 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 90987-04010 |
Relay Assy (FOR HEATER BLOWER MOTOR)
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 85916P — Relay, Headlamp | ||||
| 90987-02016 |
Relay, Headlamp
2001-07 → 2003-04
ended
|
ACV30,MCV30 JPP | — | |
| 90987-02025 |
Relay, Headlamp
2003-04 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 90987-02025 |
Relay, Headlamp
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 85916W — Relay, Adjustable Pedal | ||||
| 90987-02020 |
Relay, Adjustable Pedal
2001-07 → 2003-07
ended
|
ACV30,MCV30 JPP ATM | — | |
| 90987-02027 |
Relay, Adjustable Pedal
2003-07 → 2004-06
ended
|
ACV30,MCV3# JPP ATM | — | |
| 90987-02027 |
Relay, Adjustable Pedal
2004-06 → —
|
ACV30,MCV3# JPP 5FC | — | |
| 85927 — Relay, Cooling Fan | ||||
| 90080-87008 note |
Relay, Cooling Fan
2001-07 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 90987-02012 note |
Relay, Cooling Fan
2001-07 → 2003-03
ended
|
ACV30,MCV30 JPP | — | |
| 90987-02027 note |
Relay, Cooling Fan
2003-03 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 90987-02027 |
Relay, Cooling Fan
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 85927A — Relay, Cooling Fan, NO.2 | ||||
| 90080-87009 note |
Relay, Cooling Fan, NO.2
2001-07 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 90987-04004 note |
Relay, Cooling Fan, NO.2
2001-07 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 90987-04004 |
Relay, Cooling Fan, NO.2
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 85927B — Relay, Cooling Fan, NO.3 | ||||
| 90080-87008 note |
Relay, Cooling Fan, NO.3
2001-07 → 2003-01
ended
|
MCV30 JPP | — | |
| 90080-87008 note |
Relay, Cooling Fan, NO.3
2001-07 → 2003-07
ended
|
MCV30 JPP SE 5FC | — | |
| 90080-87008 note |
Relay, Cooling Fan, NO.3
2001-07 → 2004-06
ended
|
ACV30,MCV31 JPP;MCV30 JPP (LE,XLE) +1 | — | |
| 90987-02012 note |
Relay, Cooling Fan, NO.3
2001-07 → 2003-01
ended
|
MCV30 JPP | — | |
| 90987-02012 note |
Relay, Cooling Fan, NO.3
2001-07 → 2003-03
ended
|
ACV30 JPP;MCV30 JPP 5FC | — | |
| 90987-02027 note |
Relay, Cooling Fan, NO.3
2003-03 → 2004-06
ended
|
ACV30,MCV31 JPP;MCV30 JPP (LE,XLE) | — | |
| 90987-02027 note |
Relay, Cooling Fan, NO.3
2003-03 → 2003-07
ended
|
MCV30 JPP SE | — | |
| 90987-02027 |
Relay, Cooling Fan, NO.3
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 85934 — Relay, Magnet-clutch | ||||
| 90987-02028 |
Relay, Magnet-clutch
2001-07 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 90987-02028 |
Relay, Magnet-clutch
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 86530 — Relay Assy, Horn | ||||
| 90987-02012 |
Relay Assy, Horn
2001-07 → 2003-04
ended
|
ACV30,MCV30 JPP | — | |
| 90987-02027 |
Relay Assy, Horn
2003-04 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 90987-02027 |
Relay Assy, Horn
2004-06 → —
|
ACV30,MCV3# JPP | — | |
| 89427 — Switch, Temperature Detect | ||||
| 89428-21010 |
Switch, Temperature Detect
2001-07 → 2004-06
ended
|
MCV3# JPP | — | |
| 89428-21010 |
Switch, Temperature Detect
2004-06 → —
|
MCV3# JPP | — | |
| 89438 — Switch, Power Steering Oil Pressure | ||||
| 89438-33010 |
Switch, Power Steering Oil Pressure
2001-07 → 2004-06
ended
|
ACV30,MCV3# JPP | — | |
| 89438-33010 |
Switch, Power Steering Oil Pressure
2004-06 → —
|
ACV30,MCV3# JPP | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
