Toyota Solara
1998-06 → 2002-12 · chassis ACV20,MCV20,SXV20 · catalogue 286410 · United States
Discontinued model
Data version 2003-07
Side Moulding
27 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 61395B | Dust Proof, Center Pillar, RH |
| 61396D | Dust Proof, Center Pillar, LH |
| 61667L | Spacer, Quarter Panel, NO.1 |
| 61668H | Spacer, Quarter Panel, NO.2 |
| 62371A | Retainer, Roof Side Rail Weather Strip, Rear RH |
| 62372A | Retainer, Roof Side Rail Weather Strip, Rear LH |
| 62751G | Weatherstrip, Quarter Window Glass, Outer RH |
| 62752D | Weatherstrip, Quarter Window Glass, Outer LH |
| 62785H | Spacer, Quarter Window Glass |
| 62786F | Spacer, Quarter Window Glass, NO.2 |
| 62791G | Moulding, Quarter Window, Upper RH |
| 62792V | Moulding, Quarter Window, Upper LH |
| 64311D | Moulding, Back Belt |
| 68211A | Clip, Door Belt Moulding |
| 75551 | Moulding, Roof Drip Side Finish, RH |
| 75552 | Moulding, Roof Drip Side Finish, LH |
| 75623A | Moulding, Front Fender, Outside Rear RH |
| 75624A | Moulding, Front Fender, Outside Rear LH |
| 75651 | Moulding, Quarter, Outside RH |
| 75652 | Moulding, Quarter, Outside LH |
| 75710 | Moulding Assy, Front Door Belt, RH |
| 75720 | Moulding Assy, Front Door Belt, LH |
| 75731A | Moulding, Front Door, Outside RH |
| 75732A | Moulding, Front Door, Outside LH |
| 75851 | Moulding, Rocker Panel, RH |
| 75852 | Moulding, Rocker Panel, LH |
| 75868B | Clip, Rocker Panel Moulding, NO.2 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
