Toyota Solara

2003-07 → 2008-12 · chassis ACV30,MCV31 · catalogue 286420 · United States

Supported model Data version 2008-11

Instrument Panel & Glove Compartment

34 part groups · 4 illustrations

PNC	Description
55054	Stopper Sub-assy, Glove Compartment Door
55306A	Brace Sub-assy, Instrument Panel, NO.1
55307C	Brace Sub-assy, Instrument Panel, NO.2
55308C	Bracket Sub-assy, Instrument Panel, Center
55328	Pin, Instrument Panel, NO.1
55330B	Reinforcement Assy, Instrument Panel
55345A	Clip, Instrument Panel, NO.1
55394B	Bolt, Instrument Panel
55401E	Pad Sub-assy, Instrument Panel Safety
55404C	Panel Sub-assy, Instrument Cluster Finish, NO.2
55405B	Panel Sub-assy, Instrument Cluster Finish, Center
55406C	Insert Sub-assy, Instrument Panel, Lower LH
55409A	Panel Sub-assy, Instrument Panel Speaker
55409F	Panel Sub-assy, Instrument Panel Speaker, NO.2
55420A	Panel Assy, Instrument Cluster Finish, Center
55422A	Panel, Instrument Cluster Finish, Lower
55427D	Retainer, Instrument Finish Panel, Lower, NO.1
55432A	Panel, Instrument Panel Finish, Lower RH
55432B	Panel, Instrument Panel Finish, Lower
55433C	Panel, Instrument Panel Finish, Lower LH
55445B	Plate, Instrument Panel Finish
55458A	Cap, Instrument Panel Safety Pad
55510	Door Assy, Glove Compartment
55538A	Cover, Cooler Switch Hole
55539	Cover, Spare Switch Hole
55560A	Lock Assy, Glove Compartment Door
55606	Cover Sub-assy, Instrument Panel Under, NO.1
55650	Register Assy, Instrument Panel, NO.1
55670	Register Assy, Instrument Panel, NO.3
55961	Nozzle, Side Defroster, NO.1
55962	Nozzle, Side Defroster, NO.2
55981	Garnish, Defroster Nozzle, NO.1
73960A	Airbag Assy, Instrument Panel Passenger W/O Door
74599C	Label, Driver & Passenger Airbag Information

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
