Toyota Supra

2022-07 → present · chassis DB02,27 · catalogue 291450 · United States

Supported model Data version 2022-08
525599 · 5 callouts, 3 unlisted Full size ↗
Dashed callouts are standard fasteners the factory draws but does not list as separate parts — there is no part number behind them.
5 parts on this figure
Part number Description Fitment Price
52811A — Duct, Cool Air Intake, NO.1
53207-WAA01 note Duct, Cool Air Intake, NO.1
2022-07 → —
DB07,27 —
52821 — Duct, Air Intake, RH
52821-WAA01 Duct, Air Intake, RH
2022-07 → —
DB07,27 —
52822 — Duct, Air Intake, LH
52822-WAA01 Duct, Air Intake, LH
2022-07 → —
DB07,27 —
53285P — Duct, Cool Air Intake, LH
53285-WAA01 Duct, Cool Air Intake, LH
2022-07 → —
DB07 —
53287E — Duct, Cool Air Intake, RH
53287-WAA01 Duct, Cool Air Intake, RH
2022-07 → —
DB07 —
No quantity column: the factory catalogue records which parts a vehicle takes, never how many.
