Toyota Lexus SC300/400
1991-04 → 2000-07 · chassis UZZ30,JZZ31 · catalogue 321440 · United States
Discontinued model
Data version 2001-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 83320 — Gage Assy, Fuel Sender | ||||
| 83320-80210 |
Gage Assy, Fuel Sender
1991-04 → 1994-01
ended
|
JZZ31,UZZ30 | — | |
| 83320-80301 |
Gage Assy, Fuel Sender
1994-01 → 1996-08
ended
|
JZZ31,UZZ30 | — | |
| 83320-80301 |
Gage Assy, Fuel Sender
1996-08 → 1996-10
ended
|
JZZ31 | — | |
| 83320-80340 |
Gage Assy, Fuel Sender
1996-08 → 1996-10
ended
|
UZZ30 | — | |
| 83320-80340 |
Gage Assy, Fuel Sender
1996-10 → 1999-08
ended
|
JZZ31,UZZ30 | — | |
| 83320-80377 |
Gage Assy, Fuel Sender
1999-08 → —
|
JZZ31,UZZ30 | — | |
| 84236 — Switch Assy, Courtesy Lamp(FOR LUGGAGE COMPARTMENT ROOM) | ||||
| 84231-24040 |
Switch Assy, Courtesy Lamp(FOR LUGGAGE COMPARTMENT ROOM)
1991-04 → —
|
JZZ31,UZZ30 | — | |
| 85490A — Solenoid Assy, Fuel Lid Opener | ||||
| 85490-50010 |
Solenoid Assy, Fuel Lid Opener
1991-04 → 1994-01
ended
|
JZZ31,UZZ30 | — | |
| 85490-50020 |
Solenoid Assy, Fuel Lid Opener
1994-01 → —
|
JZZ31,UZZ30 | — | |
| 89373 — Sensor, Lamp Failure Indicator | ||||
| 89373-24080 |
Sensor, Lamp Failure Indicator
1991-04 → 1994-01
ended
|
JZZ31,UZZ30 | — | |
| 89373-24090 note |
Sensor, Lamp Failure Indicator
1991-04 → 1994-01
ended
|
JZZ31,UZZ30 | — | |
| 89373-24130 note |
Sensor, Lamp Failure Indicator
1994-01 → 1995-05
ended
|
JZZ31,UZZ30 | — | |
| 89373-24130 note |
Sensor, Lamp Failure Indicator
1995-05 → 1996-08
ended
|
UZZ30 | — | |
| 89373-24140 |
Sensor, Lamp Failure Indicator
1994-01 → 1995-05
ended
|
JZZ31,UZZ30 | — | |
| 89373-24140 |
Sensor, Lamp Failure Indicator
1995-05 → 1996-08
ended
|
JZZ31,UZZ30 USA | — | |
| 89373-24150 note |
Sensor, Lamp Failure Indicator
1996-08 → 1996-11
ended
|
UZZ30 | — | |
| 89373-24150 note |
Sensor, Lamp Failure Indicator
1996-11 → —
|
JZZ31,UZZ30 | — | |
| 89373-24160 |
Sensor, Lamp Failure Indicator
1996-08 → —
|
JZZ31,UZZ30 USA | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
