Toyota Lexus SC300/400

1991-04 → 2000-07 · chassis UZZ30,JZZ31 · catalogue 321440 · United States

Discontinued model Data version 2001-01
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Electronic Fuel Injection System

14 part groups · 3 illustrations

Illustrations

Figure 840325A 840325A 1991-04 → — Figure 840326A 840326A 1991-04 → 1997-09 Figure 841674A 841674A 1997-09 → —

Part groups

PNCDescription
85910A Relay Assy, Circuit Opening (FOR EFI)
85910F Relay, Computer (FOR EFI)
89279 Cover, Engine Control Computer
89412A Sensor, E.G.R Gas Temperature
89422 Sensor, Water Temperature (FOR E.F.I.)
89452 Sensor, Throttle Position (FOR E.F.I.)
89460 Sensor Assy, Vapor Pressure
89462 Switch, Start Injector Time
89570A Computer Assy, Fuel Pump Control
89661 Computer, Engine Control
89667 Bracket, Engine Control Computer
89668 Bracket, Engine Control Computer, NO.2
89669 Bracket, Engine Control Computer, NO.3
89672A Motor, Throttle Control
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
