Toyota Lexus GS Series
2011-12 → 2020-07 · chassis ARL10,GRL1#,GWL10 · catalogue 3324B0 · United States
Supported model
Data version 2021-03
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 15707F — Pipe Sub-assy, Oil | ||||
| 15707-36030 |
Pipe Sub-assy, Oil
2015-10 → 2019-08
ended
|
8ARFTS ARL10 | — | |
| 15770H — Gasket(FOR OIL PIPE) | ||||
| 11496-36030 |
Gasket(FOR OIL PIPE)
2015-10 → 2019-08
ended
|
8ARFTS ARL10 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
