Toyota Lexus LS400
1989-05 → 1994-10 · chassis UCF10 · catalogue 431410 · United States
Discontinued model
Data version 1995-05
Heating & Air Conditioning - Control & Air Duct
19 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 55843A | Duct, Heater TO Register, NO.1 |
| 55844 | Duct, Heater TO Register, NO.2 |
| 55845A | Duct, Heater TO Register, NO.3 |
| 55846A | Duct, Heater TO Register, NO.4 |
| 55847B | Duct, Heater TO Register, NO.5 |
| 55900B | Bulb, Air Conditioner Control |
| 55902C | Panel Sub-assy, Air Conditioner |
| 58861B | Duct, Console Box, NO.1 |
| 58862B | Duct, Console Box, NO.2 |
| 87147E | Guide, Air Heater |
| 87174F | Guide, Air Heater |
| 87211 | Duct, Air, NO.1 |
| 87212 | Duct, Air, Rear NO.1 |
| 87213 | Duct, Air, Rear NO.2 |
| 87217A | Duct, Air, Rear NO.6 |
| 87217B | Plug, Air Duct |
| 87222 | Guide, Air Duct, Rear |
| 88625C | Thermistor, Cooler |
| 88650B | Amplifier Assy, Airconditioner |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
