Toyota Lexus LS400
1994-10 → 2000-08 · chassis UCF20 · catalogue 431420 · United States
Discontinued model
Data version 2001-02
Caution Plate (EXTERIOR & INTERIOR)
13 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 11289B | Label, Spark Plug Notice |
| 11291B | Plate, Engine Name |
| 11296C | Label, Engine Service Information |
| 11297C | Label, Engine Service Information, NO.2 |
| 11298B | Label, Emission Control Information |
| 13564 | Label, Timing Belt Replacement Information |
| 17792C | Label, Engine Vacuum Hose Information |
| 74515B | Plate, Theft Warning |
| 74529 | Plate, Child Proof OR Child Protector Lock Caution |
| 74541 | Plate, Tire Pressure Caution |
| 74559A | Plate, Fuel Caution |
| 74571A | Film, Label Cover |
| 74596A | Label, Side Airbag Caution |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
