Toyota Lexus LS460/460L
2006-08 → 2012-09 · chassis USF4# · catalogue 431440 · United States
Supported model
Data version 2012-10
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 83530 — Switch Assy, Oil Pressure (FOR ENGINE) | ||||
| 83530-28020 |
Switch Assy, Oil Pressure (FOR ENGINE)
2006-08 → 2008-09
ended
|
USF4# | — | |
| 83530-28020 |
Switch Assy, Oil Pressure (FOR ENGINE)
2008-09 → 2009-09
ended
|
USF4# | — | |
| 83530-28020 note |
Switch Assy, Oil Pressure (FOR ENGINE)
2011-04 → —
|
USF4# | — | |
| 83530-28020 |
Switch Assy, Oil Pressure (FOR ENGINE)
2009-09 → 2011-04
ended
|
USF4# | — | |
| 83530-60020 note |
Switch Assy, Oil Pressure (FOR ENGINE)
2011-04 → —
|
USF4# | — | |
| 83531A — Switch, Oil Pressure | ||||
| 83531-50010 |
Switch, Oil Pressure
2006-08 → 2008-09
ended
|
USF4# | — | |
| 83531-50010 |
Switch, Oil Pressure
2008-09 → 2009-09
ended
|
USF4# | — | |
| 83531-50010 |
Switch, Oil Pressure
2009-09 → —
|
USF4# | — | |
| 84540 — Switch Assy, Neutral Start | ||||
| 84540-71010 |
Switch Assy, Neutral Start
2006-08 → 2008-09
ended
|
USF4# | — | |
| 84540-71010 |
Switch Assy, Neutral Start
2008-09 → 2009-09
ended
|
USF4# | — | |
| 84540-71010 |
Switch Assy, Neutral Start
2009-09 → 2012-09
ended
|
USF4# | — | |
| 89465 — Sensor, Oxygen | ||||
| 89465-50170 note |
Sensor, Oxygen
2006-08 → 2008-09
ended
|
USF4# | — | |
| 89465-50170 note |
Sensor, Oxygen
2008-09 → 2009-09
ended
|
USF4# | — | |
| 89465-50170 note |
Sensor, Oxygen
2009-09 → 2012-09
ended
|
USF4# | — | |
| 89465A — Sensor, Oxygen NO.2 | ||||
| 89465-50170 note |
Sensor, Oxygen NO.2
2006-08 → 2008-09
ended
|
USF4# | — | |
| 89465-50170 note |
Sensor, Oxygen NO.2
2008-09 → 2009-09
ended
|
USF40,41 | — | |
| 89465-50230 note |
Sensor, Oxygen NO.2
2008-09 → 2009-09
ended
|
USF45,46 | — | |
| 89465-50170 note |
Sensor, Oxygen NO.2
2009-09 → 2012-09
ended
|
USF40,41 | — | |
| 89465-50230 note |
Sensor, Oxygen NO.2
2009-09 → 2012-09
ended
|
USF45,46 | — | |
| 89467B — Sensor, Air Fuel Ratio | ||||
| 89467-50010 note |
Sensor, Air Fuel Ratio
2006-08 → 2008-09
ended
|
USF4# | — | |
| 89467-50010 note |
Sensor, Air Fuel Ratio
2008-09 → 2009-09
ended
|
USF40,41 | — | |
| 89467-50030 note |
Sensor, Air Fuel Ratio
2008-09 → 2009-09
ended
|
USF45,46 | — | |
| 89467-50030 note |
Sensor, Air Fuel Ratio
2009-09 → 2012-09
ended
|
USF45,46 | — | |
| 89467-50050 note |
Sensor, Air Fuel Ratio
2009-09 → 2012-09
ended
|
USF40,41 | — | |
| 89467C — Sensor, Air Fuel Ratio, NO.2 | ||||
| 89467-50020 note |
Sensor, Air Fuel Ratio, NO.2
2006-08 → 2008-09
ended
|
USF4# | — | |
| 89467-50020 note |
Sensor, Air Fuel Ratio, NO.2
2008-09 → 2009-09
ended
|
USF40,41 | — | |
| 89467-50040 note |
Sensor, Air Fuel Ratio, NO.2
2008-09 → 2009-09
ended
|
USF45,46 | — | |
| 89467-50040 note |
Sensor, Air Fuel Ratio, NO.2
2009-09 → 2012-09
ended
|
USF45,46 | — | |
| 89467-50060 note |
Sensor, Air Fuel Ratio, NO.2
2009-09 → 2012-09
ended
|
USF40,41 | — | |
| 89491 — Sensor, Engine Oil Level | ||||
| 89491-50040 |
Sensor, Engine Oil Level
2006-08 → 2006-09
ended
|
USF4# | — | |
| 89491-50041 |
Sensor, Engine Oil Level
2006-09 → 2008-09
ended
|
USF4# | — | |
| 89491-50041 |
Sensor, Engine Oil Level
2008-09 → 2009-09
ended
|
USF40,41 | — | |
| 89491-50050 |
Sensor, Engine Oil Level
2008-09 → 2009-09
ended
|
USF45,46 | — | |
| 89491-50041 |
Sensor, Engine Oil Level
2009-09 → —
|
USF40,41 | — | |
| 89491-50050 |
Sensor, Engine Oil Level
2009-09 → —
|
USF45,46 | — | |
| 89491A — Gasket, Engine Oil Level Sensor | ||||
| 89493-60010 |
Gasket, Engine Oil Level Sensor
2006-08 → 2008-09
ended
|
USF4# | — | |
| 89493-60010 |
Gasket, Engine Oil Level Sensor
2008-09 → 2009-09
ended
|
USF4# | — | |
| 89493-60010 |
Gasket, Engine Oil Level Sensor
2009-09 → —
|
USF4# | — | |
| 89615 — Sensor, Knock Control | ||||
| 89615-20090 |
Sensor, Knock Control
2006-08 → 2008-09
ended
|
USF4# | — | |
| 89615-20090 |
Sensor, Knock Control
2008-09 → 2009-09
ended
|
USF4# | — | |
| 89615-20090 |
Sensor, Knock Control
2009-09 → —
|
USF4# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
