Toyota Lexus LS600HL
2007-04 → 2012-09 · chassis UVF46 · catalogue 432410 · United States
Supported model
Data version 2012-10
Heating & Air Conditioning - Cooler Piping
13 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 88460 | Condenser Assy, Cooler |
| 88474 | Dryer, Cooler |
| 88703 | Hose Sub-assy, Discharge |
| 88704 | Hose Sub-assy, Suction |
| 88706A | Tube Sub-assy, Liquid, A |
| 88707B | Tube Sub-assy, Suction, B |
| 88716A | Pipe, Cooler Refrigerant Liquid, A |
| 88719A | Sensor, Air Conditioner Pressure |
| 88726A | Pipe, Cooler Refrigerant Liquid, A |
| 88727A | Pipe, Cooler Refrigerant Suction, A |
| 88891H | Cover, Cooler, NO.1 |
| 88892X | Cover, Cooler, NO.2 |
| 88899Q | Plate, Cover |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
