Toyota Lexus LC500/500H(CP)

2017-01 → 2023-05 · chassis GWZ100,URZ100 · catalogue 433410 · United States

Supported model Data version 2024-06
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Caution Plate (EXTERIOR & INTERIOR)

22 part groups · 3 illustrations

Illustrations

Figure 744489 744489 2017-01 → — Figure 744490E 744490E 2017-01 → — Figure 744491B 744491B 2017-01 → —

Part groups

PNCDescription
11285A Label, Coolant System Notice
11293D Label, Engine Caution
11298B Label, Emission Control Information
15369A Label, Engine Oil Information
16793B Label, Cooling Fan Information
28812A Label, Sub-battery Information
28898D Label, Battery Information
42661 Label, Tire Pressure Information
42666A Label, Run Flat Tire Caution
45248A Label, Steering Actuator Caution
74511F Label, Name (IDENTIFICATION LASER LABEL)
74515C Label, Theft Warning Information
7452A Label, Shift Control Information
74559A Plate, Fuel Caution
74559B Label, Fuel Information
74559C Label, Fuel Information, NO.2
74596A Label, Side Airbag Caution
74599B Label, Driver & Passenger Airbag Information
81192A Seal, Headlamp
88723J Label, Cooler Service Caution, NO.2
G9275 Label, Battery Caution, NO.1
G92A1 Label, Hybrid Coolant System Information
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
