Toyota Lexus RX300
1998-01 → 2003-02 · chassis MCU1# · catalogue 521410 · United States
Discontinued model
Data version 2003-10
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 04111 — Gasket Kit, Engine Overhaul | ||||
| 04111-20050 |
Gasket Kit, Engine Overhaul
1998-01 → 1999-08
ended
|
1MZFE MCU1# | — | |
| 04111-20100 |
Gasket Kit, Engine Overhaul
1999-08 → 2000-07
ended
|
1MZFE MCU1# | — | |
| 04111-20160 |
Gasket Kit, Engine Overhaul
2000-07 → —
|
1MZFE MCU1# | — | |
| 04112 — Gasket Kit, Engine Valve Grind | ||||
| 04112-20040 |
Gasket Kit, Engine Valve Grind
1998-01 → 1999-08
ended
|
1MZFE MCU1# | — | |
| 04112-20090 |
Gasket Kit, Engine Valve Grind
1999-08 → 2000-07
ended
|
1MZFE MCU1# | — | |
| 04112-20150 |
Gasket Kit, Engine Valve Grind
2000-07 → —
|
1MZFE MCU1# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
