Toyota Lexus RX300
1998-01 → 2003-02 · chassis MCU1# · catalogue 521410 · United States
Discontinued model
Data version 2003-10
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 19100P — Plug, Spark | ||||
| 90080-91180 note |
Plug, Spark
2002-01 → 2003-02
ended
|
1MZFE MCU10 | — | |
| 90919-01210 note |
Plug, Spark
1998-01 → 2002-01
ended
|
1MZFE MCU1# | — | |
| 90919-01210 note |
Plug, Spark
2002-01 → 2003-02
ended
|
1MZFE MCU10 | — | |
| 90919-01210 note |
Plug, Spark
2002-01 → 2003-02
ended
|
1MZFE MCU1# | — | |
| 19500 — Coil Assy, Ignition | ||||
| 90080-19016 note |
Coil Assy, Ignition
2002-01 → —
|
1MZFE MCU10 | — | |
| 90919-02234 |
Coil Assy, Ignition
1998-01 → 2002-01
ended
|
1MZFE MCU1# | — | |
| 90919-02234 |
Coil Assy, Ignition
2002-01 → —
|
1MZFE MCU15 | — | |
| 90919-02234 note |
Coil Assy, Ignition
2002-01 → —
|
1MZFE MCU10 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
