Toyota Lexus RX300
1998-01 → 2003-02 · chassis MCU1# · catalogue 521410 · United States
Discontinued model
Data version 2003-10
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 53383B — Seal, Hood TO Cowl Top | ||||
| 53383-48010 |
Seal, Hood TO Cowl Top
1998-01 → —
|
MCU1# | — | |
| 55359C — Coshion, Instrument Panel, NO.5 | ||||
| 55359-22040 |
Coshion, Instrument Panel, NO.5
1998-01 → —
|
MCU1# | — | |
| 55701 — Panel Sub-assy, Cowl | ||||
| 55700-48020 |
Panel Sub-assy, Cowl
1998-01 → —
|
MCU1# | — | |
| 55701J — Panel Sub-assy, Cowl Top, Outer | ||||
| 55701-48901 |
Panel Sub-assy, Cowl Top, Outer
1998-01 → —
|
MCU1# | — | |
| 55713A — Panel, Cowl Top Side, RH | ||||
| 55705-48010 |
Panel, Cowl Top Side, RH
1998-01 → —
|
MCU1# | — | |
| 55714A — Panel, Cowl Top Side, LH | ||||
| 55706-48010 |
Panel, Cowl Top Side, LH
1998-01 → —
|
MCU1# | — | |
| 55736 — Seal, Water Guard Plate | ||||
| 55736-48010 |
Seal, Water Guard Plate
1998-01 → —
|
MCU1# | — | |
| 55737B — Seal, Heater Air Duct Splash Shield, NO.1 | ||||
| 55737-48010 |
Seal, Heater Air Duct Splash Shield, NO.1
1998-01 → —
|
MCU1# | — | |
| 55738D — Seal, Heater Air Duct Splash Shield, NO.2 | ||||
| 55738-48010 |
Seal, Heater Air Duct Splash Shield, NO.2
1998-01 → —
|
MCU1# | — | |
| 55781D — Louver, Cowl Top Ventilator, RH | ||||
| 55781-48020 |
Louver, Cowl Top Ventilator, RH
1998-01 → —
|
MCU1# | — | |
| 55781-48030 note |
Louver, Cowl Top Ventilator, RH
1998-01 → —
|
MCU1# | — | |
| 55782D — Louver, Cowl Top Ventilator, LH | ||||
| 55782-48020 |
Louver, Cowl Top Ventilator, LH
1998-01 → —
|
MCU1# | — | |
| 55783A — Pad, Cowl Top Silencer | ||||
| 55783-22110 |
Pad, Cowl Top Silencer
1998-01 → —
|
MCU1# | — | |
| 55794A — Bracket, Weatherstrip Wiper Pivot Guide, NO.2 | ||||
| 55794-48020 |
Bracket, Weatherstrip Wiper Pivot Guide, NO.2
1998-01 → —
|
MCU1# | — | |
| 55799C — Clip, Cowl Top Ventilator Louver | ||||
| 90467-10146 |
Clip, Cowl Top Ventilator Louver
1998-01 → —
|
MCU1# | — | |
| 56111 — Glass, Windshield | ||||
| 56111-48030 note |
Glass, Windshield
1998-01 → 2000-07
ended
|
MCU1# | — | |
| 56111-48040 note |
Glass, Windshield
1998-01 → 2000-07
ended
|
MCU1# | — | |
| 56111-48050 note |
Glass, Windshield
1999-08 → 2000-07
ended
|
MCU15 | — | |
| 56111-48060 note |
Glass, Windshield
2000-07 → —
|
MCU1# | — | |
| 56111-48070 note |
Glass, Windshield
2000-07 → —
|
MCU1# | — | |
| 56111-48080 note |
Glass, Windshield
2000-07 → —
|
MCU15 | — | |
| 56115A — Stopper, Windshield Glass, NO.1 | ||||
| 56115-22010 |
Stopper, Windshield Glass, NO.1
1998-01 → —
|
MCU1# | — | |
| 56116C — Stopper, Windshield Glass, NO.2 | ||||
| 56116-22050 |
Stopper, Windshield Glass, NO.2
1998-01 → —
|
MCU1# | — | |
| 56117A — Dam, Window Glass Adhesive | ||||
| 56117-48010 |
Dam, Window Glass Adhesive
1998-01 → —
|
MCU1# | — | |
| 56118A — Dam, Window Glass Adhesive, NO.2 | ||||
| 56118-48010 |
Dam, Window Glass Adhesive, NO.2
1998-01 → —
|
MCU1# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
