Toyota Lexus RX450HL/350L
2017-12 → 2022-09 · chassis GGL2#,GYL26 · catalogue 522430 · United States
Supported model
Data version 2023-05
Valve Body & Oil Strainer (ATM)
16 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 35210A | Valve, Solenoid(SL1) |
| 35210B | Valve, Solenoid(SL3) |
| 35210E | Valve, Solenoid(SL5) |
| 35220A | Valve, Solenoid(SL2) |
| 35220B | Valve, Solenoid(SL4) |
| 35240E | Valve, Solenoid(S1) |
| 35240F | Valve, Solenoid(S2) |
| 35280A | Valve, Solenoid(SLU) |
| 35285 | Plate, Solenoid Lock |
| 35290C | Valve, Solenoid(SLT) |
| 35330 | Strainer Assy, Valve Body Oil |
| 35410 | Body Assy, Transmission Valve |
| 35418 | Valve, Manual |
| 35482B | Clamp, Temperature Sensor |
| 35882A | Tube, Differential Gear Lube Apply |
| 82125J | Wire, Transmission |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
