Toyota Lexus RX Series(Tmmc
2022-10 → present · chassis AALH15,TALA1#,TALH17 · catalogue 523440 · United States
Supported model
Data version 2022-09
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 35409D — Spring Sub-assy, Manual Detent | ||||
| 35409-48060 |
Spring Sub-assy, Manual Detent
2022-10 → —
|
TALA1# | — | |
| 35501 — Rod Sub-assy, Parking Lock | ||||
| 35501-48040 |
Rod Sub-assy, Parking Lock
2022-10 → —
|
TALA1# | — | |
| 35502D — Lever Sub-assy, Manual Valve Link | ||||
| 35502-48010 |
Lever Sub-assy, Manual Valve Link
2022-10 → —
|
TALA1# | — | |
| 35503B — Shaft Sub-assy, Manual Valve Link | ||||
| 35503-48010 |
Shaft Sub-assy, Manual Valve Link
2022-10 → —
|
TALA1# | — | |
| 35506 — Shaft Sub-assy, Manual Valve Lever | ||||
| 35506-78020 |
Shaft Sub-assy, Manual Valve Lever
2022-10 → —
|
TALA1# | — | |
| 35506F — Seal, Oil (FOR MANUAL VALVE LEVER SHAFT) | ||||
| 90301-A0063 |
Seal, Oil (FOR MANUAL VALVE LEVER SHAFT)
2022-10 → —
|
TALA1# | — | |
| 35506J — Spring, Retainer (FOR MANUAL VALVE LEVER SHAFT) | ||||
| 90524-09004 |
Spring, Retainer (FOR MANUAL VALVE LEVER SHAFT)
2022-10 → —
|
TALA1# | — | |
| 35556 — Shaft, Parking Lock Pawl | ||||
| 35556-48030 |
Shaft, Parking Lock Pawl
2022-10 → —
|
TALA1# | — | |
| 35557 — Pawl, Parking Lock | ||||
| 35557-48040 |
Pawl, Parking Lock
2022-10 → —
|
TALA1# | — | |
| 35557A — Spring, Torsion (FOR PARKING LOCK PAWL) | ||||
| 90508-29030 |
Spring, Torsion (FOR PARKING LOCK PAWL)
2022-10 → —
|
TALA1# | — | |
| 35596 — Plate, Pawl Stopper | ||||
| 35596-06010 |
Plate, Pawl Stopper
2022-10 → —
|
TALA1# | — | |
| 35598 — Sleeve, Parking Lock | ||||
| 35598-06020 |
Sleeve, Parking Lock
2022-10 → —
|
TALA1# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
